300W Boosting Bicycle Hydrogen Fuel Cell
$1,034.00
Professional 100Kw Fuel Cell Low Noise Direct Methanol Fuel Cell Small For Cogeneration
- Category: >>>
- Supplier: WOBO Industrial Group Inc
Share on (10000019798939):
Product Overview
Description
Safe and Reliable Methanol Reformer Hydrogen Fuel Cells
Hot Selling 100Kw Fuel Cell Small Methanol Fuel Cell for Hydrogen Production
Product Description
The methanol fuel cell adopts advanced electrochemical technology to convert methanol into electrical energy. The product mainly consists of electrodes, electrolytes and a casing. The electrode material uses a high-performance catalyst to improve the reaction efficiency. The electrolyte has good ionic conductivity to ensure the stable performance of the battery. The casing is made of strong and durable materials and has waterproof, dustproof and shockproof properties. The size is moderate, which is convenient for installation and use. When in use, just inject methanol into the fuel tank, and the battery will start automatically and
generate electricity.
generate electricity.
Product Parameters
Fuel Cell Type | High-temperature Proton Exchange Membrane Fuel Cell | Hydrogen Source | Methanol Reforming for Hydrogen Production, Atmospheric Pressure, On-Demand | |||
Rated Power | 5kW | Power Range | 0~5.4kW | |||
Rated Voltage | 72V | Rated Current | 70A | |||
Output Voltage Range | DC+50~80V | Output Current Range | 0~80A | |||
Size | 850x450x200mm | Weight | 65KG | |||
Normal Startup Time | ≤15min | Cold Start Time | <30min | |||
Operating Temperature | -40℃~+50℃ | -40°℃Startup | Feasible with the addition of insulation and other components for maintaining temperature. | |||
Standby Power Consumption | <100W | Tailpipe Emissions | CO2+water vapor,no NOx or SOx emissions | |||
Volume | 76.5L | Fuel Consumption | ≤1L/kWh | |||
Methanol-Water Ratio | 54% methanol: 46% water | Cooling System | Air-cooled | |||
Fuel Cell Stack Efficiency | ≥46% | Overall System Efficiency | >62.45% | |||
Combined Heat and Power Efficiency | ≥85% | Operating Mode | Can be operated individually, in a network, or controlled remotely. | |||
Service Life | >5000H | Noise Limit | ≤70dB | |||
Altitude | ≤4000M | Maintenance Components | Equipped with air filters and methanol-water filter elements. | |||
Fuel Tank Capacity | 40L/80L/120L/… | Integrated Lithium Battery Pack | 5kWh/10kWh/… | |||
For more information, please contact us. | ||||||
The main advantages include
High hydrogen production efficiency: Through systematic control of pressure and temperature, the methanol reforming fuel cell power generation system achieves efficient conversion of methanol and water, with a reaction rate of over 99%.
Modular design for various power combinations: Regardless of voltage or capacity, different types of applications can be accommodated through modular combinations to meet different scenarios' needs.
High comprehensive performance: The methanol reforming hydrogen fuel cell system features high energy density, low emissions, high safety, low noise, long service life, simple maintenance, and strong environmental adaptability.
Wide range of raw materials: Methanol, as the raw material, is widely distributed, easy to transport, and has a stable price with a downward trend.
Detailed Photos
Main Solutions
In situations without access to the power grid, as long as there is sufficient supply of methanol fuel, the methanol micro power plant will continue to provide power to the load equipment theoretically for an unlimited 24/7 period.
Applicable scenarios:
* Base stations or sites without access to grid power
* Base stations or sites temporarily without grid power due to factors such as construction, disputes, or relocation
* Places like islands, border outposts, civil air defense facilities, etc., lacking grid power supply
* Base stations or sites without access to grid power
* Base stations or sites temporarily without grid power due to factors such as construction, disputes, or relocation
* Places like islands, border outposts, civil air defense facilities, etc., lacking grid power supply
During normal grid power supply, the methanol micro power plant remains in standby mode, providing power to the load via a DC rectifier. In the event of a power outage, the methanol micro power plant automatically starts up, delivering reliable and stable power to equipment at base stations or substations. With methanol supply available, the methanol micro power plant will continue to power the load equipment theoretically indefinitely until grid power is restored. Once grid power is restored, the methanol micro power plant automatically shuts down and returns to standby mode.
Applicable scenarios:
* Base stations or sites in areas prone to frequent power outages, with limited transportation access, or located in remote mountainous regions
* Critical base stations or sites such as VIP or nodal stations requiring uninterrupted power supply
* Base stations or sites in urban or sensitive areas where noise and vibration levels must be minimized
* Tourist attractions or sites with special power supply requirements
* Base stations or sites in areas prone to frequent power outages, with limited transportation access, or located in remote mountainous regions
* Critical base stations or sites such as VIP or nodal stations requiring uninterrupted power supply
* Base stations or sites in urban or sensitive areas where noise and vibration levels must be minimized
* Tourist attractions or sites with special power supply requirements
Product Application
