Hot Sale Steel Coil Slitting Line slitter line Metal Coil Slitting Machine
- Category: Coil Slitting Machine >>>
- Supplier: Shijiazhuang Teneng Electrical & Mechanical Equipment Co. Ltd.
Share on (1004430755):
Product Overview
Description
Product Description
The technical flow of the Slitting line:
Coil car and storage→ Uncoiler→shovel board device → Flattening → Shear the ends →Centering device→Disc shear Slitter→Rewinder → Platform →Locating expanding set→Recoiler→Active support,hold down arm and table→Discharge Coil car
Raw Material Feeding | CR Coil, Galvanized steel, HR coil |
Material Tensile Strength | Max 550MPa |
Material Yield Strength | Max 235MPa |
Coil OD | 1100mm to 2000mm |
Coil ID | 508mm&610mm (customer order) |
Coil Weight | Max 25000 kg |
Coil Width | Min 800mm, Max 1250mm |
Coil Thickness | Min0.5mm, Max3.0 mm |
Width Tolerance | ≤0.10mm |
Burr Tolerance | ≤3% thickness |
Slitting running speed | Once 0.5-2.0mm, 0-80m/min Once over 2.0mm, 0-40m/min |
Slitting quantity | 3mm thickness ≤6 piece 2mm thickness ≤15 piece |
Input Power | 380V,50Hz, 3 Phrase |
Electric installed capacity | 300KW |
Floor size | 28x9.5m (length X width) |
Direction of Operation | To be confirmed by buyer |
Slit blade Shaft diameter | 260mm |
Shaft Material | 40Cr forge, tempering, mid frequency headening |
Blade size | 260×420×20mm |
Blade Material | H13 |
Blade Hardness | HRC56-58 |
Product Details
Related Products
About us
Shijiazhuang Teneng Electrical & Mechanical Equipment Co., Ltd is the professional manufacturer of the welded steel pipe production line, cold roll forming line, slitting line, cut-to-length line and the related auxiliary equipment. Teneng company is the modern enterprise which capable of research and development, production and sales. Teneng is a council member of China Roll Forming Association,a president member of Hebei Steel Tube Trade Association.Teneng machines are the most effective tube manufacturing equipment available in the world.In China, the well-known users are Hebei Jingye Group, SANY Group, China Shipbuilding Industry Corporation, Chongqing Changzheng Heavy Industry Co., Ltd etc.
