Product Overview
Description
PERFORMANCE | Maximum engine power at 2.250 rpm | 50 hp* |
Engine speed Maximum Torque at 1,400 rpm | 44 hp** 212 Nm | |
ENGINE | Make/type | Perkins/ AD 3.152 |
No of cylinders | 3 | |
Cooling | Water | |
Air cleaner type | Oil Bath | |
CLUTCH | Type | Dual clutch |
TRANSMISSION | Type | Sliding spur |
Number of gears | 8 forward, 2 reverse | |
POWER TAKE OFF | Engine speed at 540 PTO rpm | 1.789rpm |
HYDRAULICS | Max. Lift capacity with Lower link horizontal | 1.415 kg |
Lower links | Cat. 1& 2 with Interchangeable balls | |
STEERING | Steering Brake Type Front Axle | Manual Our Board drum brakes Mechanical Box Section Adjustable |
INSTRUMENTATION | Gauges | Tachometer, Hour meter, Fuel Level, Battery Condition & water Temperature. |
TYRE
| Front Rear | 6.00-16 (6PR) 12.4/11-28(6pr |
Weight & Dimensions | Gross weight | 1,690 Kgs. |
Over all Length | 3,260 mm | |
Overall Width minimum | 1,651mm | |
Standard Equipment | Chain Stabilizers, Check Chains, spring suspension seat, Flat top Fenders, Standard tool Box with set of tools. Weight frame without weights. Top Link, Cat-2 balls, Operators Manual. |
