XGMA side loader forklift manufacturer
Introduce:
Side Loader Superior Feature
The side-loader Foklifts series, XG S560 and XG S550, the main products made by Fotma Fork Lift Truck Plant, is the unique product with the longest history of production in the material handling industry in China. It is a kind of modern and efficient material handling vehicle for short distance transportation and it is especially suitable to loading/unloading, stacking and transporting in short distance for various kinds of shaped steel, aluminum product, timber, prefabricated cement, etc. So it is widely used at airports, harbors, docks, stations, warehouses, construction sites and timber storage sites.
With the advanced structure of Italian side-loader forklift and the high performance engine, it offers higher reliability and efficiency. With the fully hydraulic steering device, it is safe, reliable and easy to operate. The carriage platform can tilt 3 degrees upward/downward. The fork carriage can tilt 5 degrees upward /downward. The mast is able to move laterally. They are all controlled by hydraulic system. With an adjustable hydraulic system, the wheels will float freely on uneven ground. It is reliable, durable and easy to operate and maintain.
With the advanced structure of Italian side-loader forklift and the high performance engine, it offers higher reliability and efficiency. With the fully hydraulic steering device, it is safe, reliable and easy to operate. The carriage platform can tilt 3 degrees upward/downward. The fork carriage can tilt 5 degrees upward /downward. The mast is able to move laterally. They are all controlled by hydraulic system. With an adjustable hydraulic system, the wheels will float freely on uneven ground. It is reliable, durable and easy to operate and maintain.
| (Specifications) (Type) | Unit | XG S560 Loader | |
| Rated capacity | Kg | 6000 | |
| Max. Lifting height | mm | 3350 | |
| Max. Traveling speeds | Km/h | 21 | |
| Platform tilt-angle | ' | 3'upward/downward 3' | |
| Forks tilt-angle | ' | 5'upward/downward 5' | |
| Gradeability | % | 20 | |
Min. ground clearance | mm | 170 | |
| Min. turning radius | mm | 5100 | |
| Front / Rear tyres | 9.00-16-14PR | ||
| Platform height | mm | 5070*1240*1070 | |
| Fork length | mm | 1200*150*60 | |
Overall dimensions (L*W*H) | mm | 5170*2150*2820 | |
| Dead weight | kg | 9500 | |
