Вакуумные Трубчатые солнечные водонагреватели из нержавеющей стали (для домашнего использования)

Product Overview

Description

Haining Yinuo electric Co., Ltd manufactures and supplies all kinds of solar heaters, solar collectors.

Our professional group will design the best solar heating system solutions for your domestic house, hotel, hospital or industry plants etc commercial purpose.

Contact us freely to get the professional advice and customized solutions.



180L SUS304 Stainless Steel Solar Hot Water Heaters

( Tank capacity from 80L to 400L is available)



Specification details:

1. Solar Water Tank Capacity: 180L

2. Heat Collecting Type: Glass evacuated tube solar collector

3. Inner Storage Tank Material: Food-grade stainless steel SUS304-2B( or SUS316)

4. Tank Exterior Shell Material: SUS304 Stainless steel 0.4MM

5. Heat Insulation: High-density polyurethane foam layer with 72~80 hours heat preservation

6. Thickness of Insulation Layer: 50MM( or 55MM, 60MM)

7. Vacuum Tube: Φ58/1800mm, 18 pieces of solar vacuum tube

8. Vacuum Tube Material: Borosilicate glass 3.3

9. Vacuum Tube Absorbing Coating: AL/AL-ALN( or Cu-SS-ALN/AIN)

10. Bracket: 2.2MM thickness aluminum alloy

11. Angle of bracket: 45 ° ( can be from 10° to 50°, suitable for slope and flat roof installation)

12. Accessories: Stainless bolts & nuts, anti-aging silicon gasket, dust-proof rubber seal, air-vent pipe

13. Assistant tank: SUS304 stainless steel

14. Output Hot Water Temperature: 45 °C - 95°C

15. Designed Pressure(Tank): 0.5 Bar

16. Optional components: Intelligent Controller, Electric heater, Anode magnesium bar

17. Container loadng quantity: 41 sets/20'GP; 96 sets / 40'HQ



More models information,  please contact me freely.

Ben Xu
