Hot Selling Electronic X Ray Gold Silver Metal Tester Analyzer Gold Purity And Karat Tester,Jewelly Gold Tester Equipment
Product Description
1.Model:Pocket4
2.Analysis method:Energy dispersive X-ray fluorescence analysis method.
3.Measuring range of elements: Mg to U.
4.Simultaneously detect elements:Simultaneously detect tens of elements.
5.Processor and RAM:CPU: 667MHz, RAM:256M , Maximum expanded storage: 32G, Standard configuration: 2G , can store large amounts of data.
6.Content range: ppm~99.99%.
7.Testing time :3-30 seconds.
8.GPS,WIFI:Built-in system.
9.Battery time: Lithium battery,which can be charged, with maximum capacity of 7800mAH, can continuously work for 8 hours; Equiped with wide voltage(110V-220V) general adapter, can work under alternating current.
10.Testing object:Solid, liquid , powder.
11.Detector:25mm2 0.3mil,SDD detector.
12.Detector resolution: Lowest resolution can be 139eV .
13.Excitation source:40KV/100uA-Ag anode window miniature X light tube and high voltage source.
14.Collimator and filter:Collimator of 4.0 or 2.0 diameter, automatic switch of 6 types filter groups. 12 kinds of groups, world’s most compound mode, can satisfy various kinds of samples testing.
15.Video system:HD camera.
16.Screen :TFT-LCD touch screen, resolution 640*480.
17.Detection limit:Lowest detection limit accounts to ppm level.
18.Testing window:12mm.
20.Safety :Self-contained password manager mode.
19.Gas charging system: Helium charging at ordinary pressure system.
20.Data transmission: Digital multi channel technology, SPI data transmission, quick analysis, high counting rate, waterproof miniature USB,which can be connected to desktop computer.
21.Humidity :≤90%.
22.Temperature: -20℃~+50℃.
23.Size :234×306×82mm(L×H×W).
24.Weight:1.9Kg(with battery),1.6Kg(without battery).
Main Features:
1. Light hand-held model with easy operation for on-site quick analysis.
2. No shape or size limit for samples, which can be in solid, liquid or powder form
3. World-leading thermoelectric cooling Silicon Drift detector of excellent energy resolution Adoption of 13mm2
Be window ((larger than desktop XRF’s) detector makes up for lower excitation efficiency of mini X-ray source and help insure high precision determination.
4. A laser light positioning system to help insure accurate analysis of the sample or
component required.
5. Two rechargeable lithium batteries come with every instrument (and charger)
which last more than 8 hours
6. The trigger of the instrument can be locked in for hands-free measurement.
This is especially useful when companies utilize the Hand held Mounting Stand that makes the system more like a desktop analyzer. When the trigger is locked-in, the measurements can be controlled with the removable PDA, which has the easy to navigate software on it
7.Test results can be transferred to desktop computer from PDA for long-term storage and report generation
8. A carrying case comes with every analyzer with its durable exterior and foam lined interior.
It is the best way to safely transport the system and its accessories.
It is a real-time instrument for on-spot detection. There is neither obstruction nor limitation. Everything is easier than it was before. It is specially developed for outdoor, large project and portable detection.
