Inline Drip Irrigation Pipe Machine,Drip Irrigation Pipe With Type Dripper

Product Overview

Description

DRIP IRRIGATION PIPE MAKING MACHINE,

INTERNAL DRIP IRRIGATION PIPE PRODUCTION LINE

TAPE TYPE DRIP IRRIGATION PIPE

DRIP IRRIGATION PIPE PRODUCTION LINE WITH TAPE DRIPPER

1.1 Company Profile





CissCo Machinery Co., Ltd has been producing and supplying EXTRUSION MACHINERY for more than 10 years, having satisfied clients in more than 30 countries throughout the world. Our business model is built around the principles of outstanding customer service, reliability and high quality machinery; designed, engineered and manufactured in China.



For the best practices and more efficient use of our drip irrigation pipes production line we provide installation, setting and maintaining service including used production line rebuilding. Also we are committed to support our clients through the whole project life cycle and thus, we provide a training programme in order to upskill our clients in order to make sure that our clients can operate the line to achieve the highest efficiency and quality production at an optimized cost.





For the best investment decision or further details please do not hesitate to contact to us at your earliest convenience. You can also refer to our website to browse other product categories.





                                                www.cisscomachinery.com







1.2 Product details



CissCo Machinery Co., Ltd has been manufacturing and supplying drip irrigation pipelines for more than 8 years worldwide. Our drip irrigation production line meets the highest standards of quality and efficiency, possessing the following awards and certificates:



• Own national Invention Patent (Automatic perforating technology and monitoring system).

• European CE certificate.

• 1st prize of the application of the results of the project “Domestic development and industry on inline dripper irrigation pipe production line”.

• Awarded by China Institute of Water Resources and Hydropower Research in 2010.



After many years of research and batch production, our company has become a main supplier and service provider of inner drip irrigation system.



FlaInner dripper irrigation pipe leads the trend in this filed. The machinery can produce pipes continuously with high speed, have the pipe thickness distribute steadily, and easy to operate. Irrigation pipe can be used in cotton, fruit, vegetables, greenhouse, plant engineering and other water-saving irrigation area.

Cissco Machinery Co., Ltd. aims for excellent products, therefore the feedback from our users are very optimistic.



1.3. Technical parameters









Speed:.80--120m/min

Center Height:1000MM

Installed power:: about 130kW

Total Equipment Length:: 40m

Distance between drippers can be customized according to customer's requirements.





2. SCOPE of SUPPLY of  AGRICULTURAL DROP IRRIGATION PIPE MAKING MACHINE



No.	Description of equipments and model no.	Quantity
1	SJ-45/30 extruder for labyrinth tape	1 set
2	Mould for labyrinth tape	1 set
3	Labyrinth tape forming device	1 set
4	Cooling trough for labyrinth tape	1 set
5	Water removing device for labyrinth tape	1 set
6	Haul-off for labyrinth tape	1 set
7	Labyrinth transportation and insert device	1 set
8	SJ-60/30 extruder (for pipe)	1 set
9	SJ-20/25 single extruder(for marked line)	1 set
10	Mould for pipe	1 set
11	Vacuum sizing water tank	1 set
12	Cooling tank and water removing device	1 set
13	Haul-off and cutting device	1 set
14	Two position winder	1 set
15	PLC control system	1 set
