Good Quality And Cheaper Multi GSM/CDMA/WCDMA FWT Gateways

Product Overview

Description

The interface board of the TLD SX01W-8WAYS FWT supply a clear 8 channels bond between standard phone or a VOIP GATEWAY or A PBX and WCDMACell Network it possesses the function of the emulation phone exchanger and supply:
Features:
Dialing tone with 450hz
DTMF Dialing
Bell signal
Polarity reversal
The RJ-11 socket which connect the phone or the payment
Antenna socket (SMA)
IP usage switch
Working state indicator
Signal Strength indicator
Technical Specifications
WCDMA 2100MHZ AND GSM Module Dual band GSM 850mhz / 900mhz / 1800mhz / 1900MHz
Phone interface: supply RJ-11 Phone Interface
Hanging voltage: 48V
Picking off voltage: 30mA / 41mA
Dialing tone Frequency: 450Hz
Antenna interface: Antenna amplifying >1. 5db
Sensitivity <-104DBM
Transmitting power<3W
Adapter interface: INPUT: AC 175~260V
OUTPUT: + 12V / 1000MA
Operation Circumstance:
Operation temperature: -10c ~ 60C
Storage temperature: -20C ~ 70C
Operation humidity: 45% -95%
Atmosphere pressure: 86-106Kpa
Environment noise: < 60DB
Transmitting Power: 2W
Sensitivity: <-104dbm
Antenna Amplifying: >1. 5db
Dialing frequency: 450Hz
Hanging voltage: 45V
Picking carrent: 30mA / 41mA
Packing:
Product dimension: L455x W280 x H45mm
Gift box dimension: L510x W170x H64mm
G. W: 4. 5kg
