glass blowing lathe and the burner (accept customized design )

Product Overview

Description

we can manufacture the glass blowing lathe and the burner ,we also can do the special glass lathe according to your special requirement  !



 The speed is adjusted by transducer , the Moror is 0.75KW, the transmission
is by synchronous wheel and belt, the concentricity is 0.05mm, the
 parallelism is 0.1mm, the rotating speed is 0--300 circle/minute
  the voltage can be adjusted according to customer’s request, such as
 110v,220v,380v,..etc



The main glass lathe which we can make is as following



spindle bore:           lead rail  length:         working length between the chucks:

 65mm                            1100mm                        500mm
 80mm                            1100mm                        450mm
120mm                            1500mm                       700mm
150mm                            2000mm                       1000mm

 200mm                          2500mm                        1500mm
 250mm                          4000mm                        3000mm
 300mm                          4000mm                         2800mm
 400mm                           4000mm                        2750mm



lead rail surface quenching HRC56-60,high-accurate lead rail grind (can do the accurate line streaming lead rail according to your request !)

Headstock have synchronous belt drive ,decrease the noise of the original chain drive !

The headstock rotate synchronous ,(can do the two headstock rotate indepently according to your request ! )
The coaxiality of the chuck is less than 0.05mm
The quartz lathe is matched with heat insulation frame and burner adjusting frame !
can make various nonstandard lathe !

can manufacture various burner accoridng to your request !
