Product Overview

Description

Aluminium scrap is imported from various countries where we have tie-up with scrap yards. The scrap is segregated properly at these scrap yards and shipped as per ISRI classifications. He scraps have very low or nil attachments which enables the end user to use the scrap without further inspection. This saves valuable time for the end users resulting in lower effective cost.
Further we offer these Scraps in customized solutions as per the requirement of the client. These scraps help them in serving varied purposes of different industries mainly Extrusion and casting

Aluminum Extrusion 6063 Scrap

Aluminum Extrusion 6063 Scrap. It is the most common alloy used for aluminum extrusions. Normally, Aluminium Extrusion 6063 Scrap shall consist of clean aluminum profile extrusions including window, shop fittings, irrigation tubes and door frames. However, it must be free of screws, iron components, plastics, rubber or other foreign materials.

Chemical composition· Silicon minimum 0.2%, maximum 0.6% by weight   · Iron no minimum, maximum 0.35% · Copper no minimum, maximum 0.10% · Manganese no minimum, maximum 0.10% · Magnesium minimum 0.45%, maximum 0.95% · Chromium no minimum, maximum 0.10% · Zinc no minimum, maximum 0.10% · Titanium no minimum, maximum 0.10% · Other elements no more than 0.05% each, 0.15% total · Aluminium ; Remainder

ELEMENT	6063 % PRESENT
Si	0.2 to 0.60
Fe	0.0 to 0.35
Cu	0.0 to 0.10
Mn	0.0 to 0.10
Mg	0.45 to 0.9
Zn	0.0 to 0.1
Ti	0.0 to 0.1
Cr	0.1 max
Al	Remainder

Specifications1. Alloy: 6063-T5/T6 2. Length: 3-6.5 m 3. Normal anodizing thickness: 8 to 12 micro 4. Normal powder coating thickness: 60 – 100 micro 5. Tensile Strength: ≥160 MPa 6. Yield strength: ≥110 MPa 7. Extensibility: ≥8% 8. Hardness (HW): ≥8

Typical Applications;• Architectural and building products • Door and window frames • Electrical components and conduit • Railings and furniture • Pipe and tube for irrigation systems • Heatsinks etc

Packaging Details;1.Compressed into rectangular block 2. 50kgs/bag, 1000kgs/bag 3. 50kgs/bale, 50kgs/bundle 4. 20mt/20’fcl, 25mt/40’fcl
