Model NO. | IPSCARL400WH | |||
Camera | ||||
Image Sensor | 1/2.8" SONY Starvis Back-illuminated CMOS sensor | |||
Resolution | 4MP | |||
Effective Pixels | 2616 (H)*1964 (V) | |||
Compression | H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG | |||
TV System | PAL/NTSC | |||
Electronic Shutter Time | Auto: PAL 1/25-1/10000Sec; NTSC 1/30-1/10000Sec | |||
Minimun Illumination | 0.01Lux | |||
S/N Ratio | ≥52dB | |||
Scanning System | Progressive | |||
Video Output | Network | |||
Reset Button | Optional | |||
Lens | ||||
Focus Length | 3.6mm | |||
Focus Control | Fixed | |||
Lens Type | Fixed | |||
Pixels | 2MP | |||
Night Vision | ||||
Infrared LED | No,Support Warm light LED double3015U×2, up to 25M | |||
Infrared Distance | / | |||
IR Status | Auto Control | |||
IR Power On | Smart, Manual & Timed mode | |||
Network | ||||
Ethernet | RJ-45 (10/100Base-T) | |||
Wireless | / | |||
Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP ,PPPoE, NTP, UPnP, SMTP, UDP | |||
ONVIF | Support ONVIF 2.4(Profile S/T/G) | |||
P2P | YES, Support QR Code | |||
POE | Optional/Internal, Support IEEE 802.3af | |||
Video Delay | 0.3S (Within the Lan) | |||
Main Stream 1 | 2592*1944@30fp | |||
Main Stream 2 | 2560*1440@30fp | |||
Main Stream 3 | 1920*1080@30fps 1280*720@30fps | |||
Sub Stream 1 | 1280*720@30fps 720*480@30fps | |||
Sub Stream 2 | 352*288@30fps | |||
Sub Stream 3 | / | |||
Tri Stream | 1280*720@30fps 720*480@30fps 352*288@30fps | |||
IE Brower | IE8-11, Google Chrome, Firefox , Mac Safari | |||
Smart Phone | iPhone, iPad, Android, Android Pad | |||
AI Function | ||||
Intelligent Analysis | Face Detection, Intrusion Detetion, Line Cross Detetion, Loiter Detetion, People Gather Detecion | |||
Camera Features | ||||
Day/Night | Color/ B&W (IR-CUT ) | |||
Image Config | Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control), Video Tampering, HLC, Distortion | |||
Full Color | Support | |||
Corridor Pattern | Support | |||
Defog Mode | Support | |||
ROI | Support | |||
BLC | Support | |||
WDR | HDR: 120dB | |||
Motion Detection | Support | |||
Privacy Masking | 3 Rectangular Zone | |||
Recording Mode | NVR/CMS/Web | |||
Language | Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands,Czech, Vietnamese | |||
Interface | ||||
Audio | Optional 1 Built-in MIC,Optional Audio Input/Output | |||
Alarm | / | |||
SD Card Slot | Optional Internal, Support Max 512GB | |||
RS485 | / | |||
General | ||||
Housing | IP67 | |||
Anti-cut Bracket | NO | |||
IR Cut Filter | YES | |||
Operation Temperature | -20℃ ~ +60℃ RH95% Max | |||
Storage Temperature | -20℃ ~ +60℃ RH95% Max | |||
Power Source | DC12V±10%,1000mA | |||
Dimension | ¢96 x 96*91 mm | |||
Weight | 600g |
