AB5200 Bill Counter with Dust Cover

Product Overview

Description

Equipped with 2x stackers and 1x reject stacker, the GT-21 accurately and quickly sorts mixed banknotes by fitness, new/old style, denomination, face, and orientation.



Suitable for multiple applications and environments, the GT-21 transforms your cash management operations with enhanced fitness sorting productivity and in-branch banknote recycling, even in locations where space is at a premium. A mid-sized desktop banknote sorter that delivers fast, efficient and continuous processing of medium volumes of banknotes.

Fitness discrimination

(holes, tears, dog-ears, tape, soil, stains, folded, de-inked, graffiti etc.)



Multiple pocket setting

(ATM / Fitness / Face / Orientation / Denomination / Version )



High-speed image processing

High resolution dual CIS

High level fitness sorting

Capture and Record of OCR

Can be installed up to 10 currencies



Advanced counterfeit detection

Equipped with range of counterfeit detection technologies.



User-friendly system

Highly visible 7” Full color touch screen

Simple and easy operation

Easy maintenance



Currency	Up to 10 Currencies
Counting Speed	Fitness Sorting	800 notes/min
Pocket Capacity	Hopper	1000 notes
	Reject Pocket	Switchable 50/100 notes
	Stacker x 2	200 notes
Display	7” Full Color Graphic Touch LCD
Dimension	530(W) x 420(D) x 450(H) mm
Weight	42 kg
Power Supply	100 ~ 240 V AC, 50/60 Hz
Countable Note Size	Length	60 - 100 mm
	Width	100 - 180 mm
Counterfeit Detection	Full Line MG, CIS, IR, UV
Communication	LAN, USB(USB port x 2), RS232
Accessories	External display, Thermal printer
