FST 16S Fiber Fusion Splicing Automatically FTTX Reliable Optical Fiber Fusion Splicer Splicing Machine
- Category: >>>
- Supplier: Shenzhen Hicorpwell Technology Co. Ltd.
Share on (11000000579042):
Product Overview
Description
Products Description
FST-16S Fiber Fusion Splicing Automatically FTTX Reliable Optical Fiber Fusion Splicer Splicing Machine
Fusion Splicer FST-16S is one of the most powerful & intelligent fusion splicing machines
and adopts cladding alignment technology. It has industrial-level Quad-core CPU( Mainly 1.4 GHz ),
featuring low power cost and high performances, equipped with 5” high-resolution color LCD touch screen for easy operations.
It also provides high capacity battery of 5200mAH for working even further in the field, which is typical 280 splicing/heating
cycles.
Innovative technology brings unlimited convenience. With its excellent and stable performances,
FST-16S has become one of the most reliable and effective fusion splicer for FTTX in global market.
and adopts cladding alignment technology. It has industrial-level Quad-core CPU( Mainly 1.4 GHz ),
featuring low power cost and high performances, equipped with 5” high-resolution color LCD touch screen for easy operations.
It also provides high capacity battery of 5200mAH for working even further in the field, which is typical 280 splicing/heating
cycles.
Innovative technology brings unlimited convenience. With its excellent and stable performances,
FST-16S has become one of the most reliable and effective fusion splicer for FTTX in global market.
Model | FST-16S |
Number of Fiber | Single |
Applicable Fibers | SM(ITU-T G.652&G.657) / MM(ITU-T G.651) / DS(ITU-T G.653) / NZDS(ITU-T G.655) |
Compatible Fiber / Cable | 0.25~3.0 mm / Indoor Cable (0.9mm/2.0mm/2.4mm) |
Cleaved Length | Diameter: 0.125~1 mm / Cleave Length: 8~16 mm |
Splicing Mode | Multiple splicing modes |
Typical Splice Loss | 0.01-0.05db |
Return Loss | >> 60 dB |
Lighting | 1 Powerful White LED and Illuminated Keypads |
Splicing Time | 6~8 seconds |
Estimated Splice Loss | Available |
Protection Sleeve Length | 20~60 mm |
Heating Mode | Multi Heating Modes |
Heating Time | Typical Heating Time: 30 sec |
Records Storage | The latest 5000 Records |
Tension Test | 1.5~2.0N |
Operating Condition | Operating Altitude: 0~5000m above Sea Level, 0.95% Relative Humidity, -10~50°C, Max Wind 15m/s |
Storage Condition | 0~95% Relative Humidity, -40~80°C |
Display | 90° Bi-directional View, 5.0" 800*480 Color High Resolution Display with Touch Screen |
Fiber View & Magnification | X, Y, XY, X/Y : 500X Magnification |
Power Supply | AC Input 100-240V, DC Input 12-15V |
Battery Capacity | 5200mAh , Typical above 280 times (Splice+Heat) |
Operating Methods | Button / Touch Screen |
Automatic Calibration | Automatic ARC Calibration According to Air Pressure and Temperature |
Electrode Life | 3500 ARC, can be Extended by Using an Electrode Grinder |
Terminal | USB2.0 / Phone Jack |
Dimension | 140W x 165L x 160H mm (including rubber bumper) / 130W x 165L x 150H mm(excluding rubber bumper) |
Weight | 2.0KG (including rubber bumper) / 1.7KG (excluding rubber bumper)/ 0.38KG (battery) |
Company Profile
Our Hicorpwell Team
FAQ
Q1: Are your trading company or manufacture ?
A: We are factory verified by TUV
Q2: What is your delivery time ?
A: Generally, sample: 3~5 working days. formal order: 7-10 working days.
Q3: Do you provide OEM service ?
A: Yes, we can print your logo or label on the products or on the box.
Q4: Can you provide free samples ?
A: Some of low value samples can be free for you, but you need pay for the shipping cost.
Q5: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.
Q6: What's your payment terms ?
A: We accept T/T, Western Union, Money Gram, Paypal.
For samples: 100% payment. Formal order: 30% as deposit, 70% balance payment before shipment.
A: We are factory verified by TUV
Q2: What is your delivery time ?
A: Generally, sample: 3~5 working days. formal order: 7-10 working days.
Q3: Do you provide OEM service ?
A: Yes, we can print your logo or label on the products or on the box.
Q4: Can you provide free samples ?
A: Some of low value samples can be free for you, but you need pay for the shipping cost.
Q5: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.
Q6: What's your payment terms ?
A: We accept T/T, Western Union, Money Gram, Paypal.
For samples: 100% payment. Formal order: 30% as deposit, 70% balance payment before shipment.
If you want to know more ,Please click "Clickto contact us for more details and a competitive quotation" below to contact us’‘ , we will answer patiently all of your questions, Wish us have a happy cooperation!
