Product Overview

Description

20FT Container Dimensions Material Type Size Feet External Length Internal Capacity Used Shipping Container  New Containers

Specifications	20ft	40ft HC	Unit
External Dimension	6058*2438*2591	12192*2438*2896	MM
Internal Dimension	5898*2287*2299	12032*2288*2453	MM
Inside Cubic Capacuty	31.2	67.5	CBM
Maximum Gross Weight	30480	24000	KGS
Tare Weight	2700	5790	KGS
Maximum Payload	27780	18210	KGS
Allowable Stacking Weight	192000	192000	KGS

Corner
Floor Beam for short side	Steel: CORTEN A, thickness: 4.5mm
Floor	28mm, intensity: 7260kg
Column	Steel: CORTEN A, thickness: 6.0mm
Inner column for back side	Steel: SM50YA + channel steel 13x40x12
Wall panel-short side	Steel: CORTEN A, thickness: 2.0mm
Door Panel	Steel: CORTEN A, thickness: 2.0mm
Horizontal beam for door	Steel: CORTEN A, thickness: 3.0mm for standard container and 4.0mm for high cube container

Let us know what price condition you like us to quote: FOB or CIF, destination port
