BITUMEN GRADES: 40/50, 60/70 AND 80/100

Product Overview

Description

BITUMEN GRADE 80/100
Characteristic	Specification	Test Method
SPECIFIC GRAVITY @25/25oC	1.01/1.05	D.70
PENETRATION @ 25oC	80/100	D.5
SOFTENING POINT oC	45/52	D.36
DUCTILITY @25oC	100 MIN	D.113
LOSS ON HEATING %WT	0.5 MAX	D.6
DROP IN PENETRATION AFTER HEATING %	20 MAX	D.5
FLASH POINT oC	225 MIN	D.92
SOLUBILITY IN TCE %WT	99.5 MIN	D.4
ORGANIC MATTER INSOLUBLE IN CS2 %WT	0.2 MAX	D.4



BITUMEN GRADE 60/70
Characteristic	Specification	Test Method
SPECIFIC GRAVITY @25/25oC	1.01 - 1.06	ASTM D-70
PENETRATION @ 25oC	60-70	ASTM D-5
SOFTENING POINT oC	49-56	ASTM D-36
DUCTILITY @25oC	100 Min	ASTM D-113
LOSS ON HEATING %WT	0.2 Max	ASTM D-6
DROP IN PENETRATION AFTER HEATING %	20 Max	ASTM D-5
