Item | Model | Heat insulation type 1 | Heat insulation type 2 | Insulated type 1 | Insulated type 2 | ||||
Material | Materials | Aluminum foil braided cloth | Aluminum foil bubble | Aluminum foil pearl cotton | Aluminum foil insulation film | ||||
Weight(G) | Weight(G) | 180-190G/M2 | 170-400G/M2 | 130-500G/M2 | 600G-1200G/M2 | ||||
Thickness(MM0 | Thickness(mm) | 0.2mm | 3mm-8mm | 1mm-6mm | 10mm-25mm | ||||
Color | Color | silver | silver | silver | silver | ||||
Tension index | transverse | 370N/25MM | 112N/25MM | 68N/25MM | 900N/25MM | ||||
longitudinal | 360N/25MM | 105N/25MM | 49N/25MM | 860N/25MM | |||||
permeability | 1.1G/M2 24H | 1.3G/M2 24H | 2G/M2 24H | 0.8G/M2 24H | |||||
Thermal reflectivity | 96.4% | 97% | 95% | 92% | |||||
elongation | transverse | 27% | 45% | 83% | 22% | ||||
longitudinal | 24% | 36% | 62% | 18% | |||||
Temperature range | -70。C/100.C | ||||||||
Oxygen permeability | Oxygen permeability | 88.86x10-6 | 101.71x10-6 | 85.23x10-6 | 120.86x10-6 | ||||
Blasting strength | 890N | 230N | 175N | 2100N | |||||
Size(M)/Weight(KG) | 1.2*1.0*1.0M | 1.4KG | 1.9KG | 1.5KG | 5.6KG | ||||
1.2*1.0*1.2M | 1.5KG | 2.1KG | 1.7KG | 6.4KG | |||||
1.2*1.0*1.5M | 1.7KG | 2.5KG | 2.1KG | 7.2KG | |||||
Technology | sewing | ||||||||
Sealing method | Zippers, Velcro, double-sided tape |
