Миниатюрный тяги Калиброванные подшипники F2 6M шаровых подшипников Сделано в Китае
- Category: >>>
- Supplier: Dongguan Charmfun Metal Tech Limited
Share on (11000004069299):
Product Overview
Description
Product Description
F2-6M is a miniature thrust grooved bearing with bore diameter of 2.5mm and outer diameter of 6mm. We manufacture the F2-6M thrust bearings with high quality and low prices.
F2-6M Thrust Ball Bearing Specifications
Part Number: F2-6M
Bearing Type: Ball
Structure: Thrust Ball
Load Direction: Axial
Raceway Type: groove raceway
Bore Diameter of Shaft Washer(d): 2.5mm
Outer Diameter of housing washer(D): 6.0mm
Bore Diameter of housing washer(d1): 2.7mm
Outer Diameter of shaft washer(D1): 6.8mm
Thickness(H): 3.5mm
Radius: 0.1mm
Washers Material: Chrome steel 52100(Gcr15)
Cage Material: Bronze or stainless steel
Ball Material: Chrome steel 52100(Gcr15)
Grade: ABEC-1 (higher grade available)
Clearance: C0 (other clearance available)
Ball Size: 1.2mm
Ball Quantity: 6pcs
Lubrication: grease (oil available)
Temperature Range: -30℃~130℃
Net Weight(g): 0.6 grams
Dynamic Load Rating (Cr): 117N
Static Load Rating (Cor): 83N
F2-6M Thrust Ball Bearing Specifications
Part Number: F2-6M
Bearing Type: Ball
Structure: Thrust Ball
Load Direction: Axial
Raceway Type: groove raceway
Bore Diameter of Shaft Washer(d): 2.5mm
Outer Diameter of housing washer(D): 6.0mm
Bore Diameter of housing washer(d1): 2.7mm
Outer Diameter of shaft washer(D1): 6.8mm
Thickness(H): 3.5mm
Radius: 0.1mm
Washers Material: Chrome steel 52100(Gcr15)
Cage Material: Bronze or stainless steel
Ball Material: Chrome steel 52100(Gcr15)
Grade: ABEC-1 (higher grade available)
Clearance: C0 (other clearance available)
Ball Size: 1.2mm
Ball Quantity: 6pcs
Lubrication: grease (oil available)
Temperature Range: -30℃~130℃
Net Weight(g): 0.6 grams
Dynamic Load Rating (Cr): 117N
Static Load Rating (Cor): 83N
Specification
item | value |
Type | BALL |
Structure | Thrust |
Applicable Industries | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail |
Brand Name | Neutral, OEM |
Model Number | F2-6M |
Precision Rating | ABEC-1, 3, 5, 7 |
Seals Type | OPEN |
Number of Row | Single row |
Place of Origin | China |
Fujian | |
Bearing model | F2-6M |
Bearing type | ball |
Structure | ball thrust |
Load Direction | Axial |
Raceway Type | groove raceway |
Ball Size | 1.2mm |
Ball Quantity | 6pcs |
Net Weight | 0.6grams |
Dynamic Load Rating (Cr) | 117N |
Static Load Rating (Cor) | 83 N |
Packing & Delivery
The packaging of bearings will be done according to customer's requirements.
Shipping Methods
For small volume order, usually, we use DHL/Fedex/UPS for shipping; for large volume order, we use sea shipping; the shipping methods are according to customer's requirement.
Company Profile
We are a professional manufacturer of miniature ball bearing in China. Our factory was built in 2003 with a total area of 2,880 square meters. The factory production capacity now is up to 20 million sets of ball bearings each year.
We mainly specialize in manufacturing miniature ball bearings of BD (Bore Diameter) from 1mm to 12mm and OD (Outer Diameter) from 3mm to 40mm. The top precision level of our ball bearings is up to ABEC-9.
The types of our ball bearings are mainly deep groove ball bearing, flanged ball bearing and thrust ball bearing. We have ball bearings made of stainless steel, chrome steel, bearing steel and ceramic. Our ball bearings have been applied in various products in many industries.
We stick to offering customers high quality products with competitive prices, short lead time and excellent services. We make stock for most of the models to ensure the prompt delivery to customers for small quantity orders.
We mainly specialize in manufacturing miniature ball bearings of BD (Bore Diameter) from 1mm to 12mm and OD (Outer Diameter) from 3mm to 40mm. The top precision level of our ball bearings is up to ABEC-9.
The types of our ball bearings are mainly deep groove ball bearing, flanged ball bearing and thrust ball bearing. We have ball bearings made of stainless steel, chrome steel, bearing steel and ceramic. Our ball bearings have been applied in various products in many industries.
We stick to offering customers high quality products with competitive prices, short lead time and excellent services. We make stock for most of the models to ensure the prompt delivery to customers for small quantity orders.
FAQ
Q1. Are you manufacturer or trader?
A: We are professional miniature ball bearings manuafcturer since 2003.
A2. Do You Accept Customization?
A: YES, we welcome customer's customization orders.
Q3.How Long is Your Lead Time?
A: 1 - 3 days for stock items; 7 - 15 days for production items.
Q4. Do You Provide Samples?
A: YES, we provide samples to customers FREE of charger, customers need to pay for the shipping cost.
Q5. What is Your Terms of Payment?
Payment<=2,000USD, 100% in advance. Payment>2,000USD, 30% T/T in advance, balance before shipment.
A: We are professional miniature ball bearings manuafcturer since 2003.
A2. Do You Accept Customization?
A: YES, we welcome customer's customization orders.
Q3.How Long is Your Lead Time?
A: 1 - 3 days for stock items; 7 - 15 days for production items.
Q4. Do You Provide Samples?
A: YES, we provide samples to customers FREE of charger, customers need to pay for the shipping cost.
Q5. What is Your Terms of Payment?
Payment<=2,000USD, 100% in advance. Payment>2,000USD, 30% T/T in advance, balance before shipment.
Q6: What is Your Terms of Warranty?
A: There are different warranty for different items, please contact us for details.
A: There are different warranty for different items, please contact us for details.
F2-6M Ball Thrust Bearings manufacturer from China.
