New Launch Syble XB-X86 1D 2D Omnidirectional Desktop Barcode Scanner Usb Wired Platform Qr codes scanning supermarket
Product Description
Specification
Model Number | XB-X86 |
| Performance Parameters | |
| Light Sources | Red LED |
| Supported Symbologies | 1D:Codabar,Code 11,Code 39/Code 93,Code 128/EAN128, Interleaved 2 of 5,Matrix 2 of 5,MSI Code,Industrial 2 of 5,GS1 Databa 2D:QR code,Data Matrix,PDF417 |
| System compatibility | Linux, Android, Windows XP/7/8/10 |
| Scan Range | 20-200mm(EAN13 13MIL, PCS=90%) |
| Print Contrast | 20% minimum reflective difference |
| Minimum recognition accuracy | Code39 4mil |
| Motion Tolerance | 4 meters/sec |
| Scan Mode | Automic Induction Scanning |
| Image(Piexls) | 640 piexls(H) x 480 piexls(V)Indicator |
| Interface | USB(Drive-Free),USB-COM,RS232 |
| Recognition angle range | Turn ±360°, Elevation ±65°,Declination ±65° |
| Physical Parameters | |
| Weight | 294.4g |
| Material | ABS+PC |
| Cable Length | 2M |
| Dimension | 96.8*79*151.4mm |
| Environmental Parameters | |
| Operating Temperature | 0℃~50℃ |
| Storage Temperature | -40℃~70℃ |
| Relative Humidity | 0%~95% RH(Non-condensing/ Non-freezing) |
| Shock Resistance | Withstands multiple times 1.5meters drops to concrete |
| Electrical Parameters | |
| Working Voltage | DC5V±5% |
| Current | Standby Current 190mA; Working Current 240mA |
