Flexible-Twistable Waveguide
The utility model relates to a bendable and twisted interlocking soft waveguide, which comprises a soft wave guide, a first flange and a protective sleeve; Including soft wave catheter; The inner wall of the soft wave catheter is provided with a corrugated part, and the outer side of the soft wave catheter is sleeved with a protective sleeve; The two ends of the soft wave conduit are respectively provided with a first flange and a second flange
The flange plate and the soft wave conduit are fixed by welding, the four corners of the first flange plate are provided with the first screw hole, and the second flange plate is provided with the second screw hole corresponding to the first screw hole; One side of the first flange is provided with an annular groove; The utility model achieves the purpose of interlocking the two soft wave conduits through the cooperation between the annular protrusion, the annular groove and the adjusting bolt, and the interlocking fixation of the annular protrusion and the annular groove is more firm through the adjusting bolt. Compared with the traditional fixation method which only uses the flange bolt, the fixation method is more stable, so as to improve the service life.
The flange plate and the soft wave conduit are fixed by welding, the four corners of the first flange plate are provided with the first screw hole, and the second flange plate is provided with the second screw hole corresponding to the first screw hole; One side of the first flange is provided with an annular groove; The utility model achieves the purpose of interlocking the two soft wave conduits through the cooperation between the annular protrusion, the annular groove and the adjusting bolt, and the interlocking fixation of the annular protrusion and the annular groove is more firm through the adjusting bolt. Compared with the traditional fixation method which only uses the flange bolt, the fixation method is more stable, so as to improve the service life.
Specification
Name | Waveguide High Power Termination | ||
Specification | WR51-WR229(EIA)/BJ40-BJ180(GB)&Customized | ||
Frequency(GHz) | 3.22-22.0 | ||
VSWR | ≤1.15 | ||
Insertion loss(dB) | 0.15 | ||
Average power(Kw) | 2.5 | ||
Peak power(Kw) | 500 | ||
Material | Silver plated copper strip | ||
Length(mm) | 50-3000 | ||
Operation temperature(℃) | -55~ 85 | ||
