China factory manufacturer polypropylene raw material ppr plastic pipe with different size for hot water plumbing material
- Category: >>>
- Supplier: Hangzhou Jinchang New Material Co. Ltd.
Share on (11000005322241):
Product Overview
Description
NO. | TECHNICAL DATA SHEET | ||||||||||
1 | COLOR | WHITE OR CUSTOM | |||||||||
2 | STANDARD | GB/T 18742.2-2017 | |||||||||
3 | Specification | TYPE | DN(mm) | thickness(mm) | Length(mm) | ||||||
S4 PN1.6MPa | Φ63 | 7.1 | Cold water pipe, 4m or custom | ||||||||
Φ50 | 5.6 | ||||||||||
Φ40 | 4.5 | ||||||||||
Φ32 | 3.6 | ||||||||||
Φ25 | 2.8 | ||||||||||
Φ20 | 2.3 | ||||||||||
S3.2 PN2.0MPa | Φ63 | 8.6 | hot water pipe, 4m or custom | ||||||||
Φ50 | 6.9 | ||||||||||
Φ40 | 5.5 | ||||||||||
Φ32 | 4.4 | ||||||||||
Φ25 | 3.5 | ||||||||||
Φ20 | 2.8 | ||||||||||
4 | Range of usage | Suitable for cold and hot water pipe systems for inside building and temperature not higher than 75°C | |||||||||
5 | Technical Data | Hydrostatic strength | No break, no leakage | ||||||||
OIT 210℃ | ≥20min | ||||||||||
longitudinal reversion % | ≤2 | ||||||||||
Q1: Are you a factory?
A: Yes, we are factory.
Q2: Will your company supply samples?
A: Free samples and freight collect.
Q3: When is the delivery date？
A: 20-60 days after payment.
