15hp outboard motors 2 stroke marine outboard engines boat engines 15 hp
- Category: Boat Engines >>>
- Supplier: AAD,GB,2019,LIMITED
Share on:
Product Overview
Description
| Parameter | Measuring unit | T15BMS | T15BML |
| Length | mm(in.) | 873(34.4) | |
| Width | mm(in.) | 332(13.1) | |
| Height | mm(in.) | 1040(40.9) | 1167(45.9) |
| Transom height | mm(in.) | 440(17.30) | 567(22.30) |
| Net Weight | kgs | 38.5 | 40 |
| Full throttle operating range | r/min | 4000~5500 | |
| Maximum output | kw(hp)@r/m | 11(15)@5000 | |
| Idling speed | r/min | 900~1000 | |
| Engine type | 2 Stroke | ||
| Cylinder quanitity | 2 | ||
| Displacement | cm3 | 246 | |
| Bore×Stroke | mm(in.) | 56*50 (2.2*1.97) | |
| Ignition System | CDI | ||
| Control system | Tiller | ||
| Starting System | Manual | ||
| Gear positions | Forward-neutral-reverse | ||
| Gear ratio | 2.08(27/13) | ||
| Trim and tilt system | Manual tilt | ||
| Fuel tank volume | L | External 24 | |
| Maximum fuel | L/h | 7.3 | |
| Engine fuel ratio | 50:1 | ||
| Gear oil | ml | 250 | |
| Propeller specification | in | 3-9 1/4"×9" | |
