Wholesale factory mini industrial oven/high temperatures box Hot Oven/lab vacuum chamber
- Category: >>>
- Supplier: Dongguan Xinbao Instrument Co. Ltd.
Share on (11000006051833):
Product Overview
Description
Products Description
Introduction:
Vacuum drying oven is used for drying and heating test in vacuum condition of objects in scientific research units, specialty universities, industrial and mining enterprises’ laboratories together with production field, powder drying, baking and disinfection and sterilization of all kinds of glass containers.especially suitable for fast and efficient drying of thermal sensitivity, oxidization and complex components.etc.
Product Paramenters
Model | Inner chamber and outer chamber size（mm） | Consumed power | Shelf | ||
XB-OTS-6020 Desktop | 300×300×275 inner 580×450×450 outer | 400W | 1PCS | ||
XB-OTS-6030 Desktop | 340×335×265 inner 600×450×470 outer | 500W | 1PCS | ||
XB-OTS-6050 Desktop | 415×370×345 inner 720×525×535 outer | 1450W | 2PCS | ||
XB-OTS-6090T vertical( unified control each shelf) | 450×450×450 inner 615×590×1470 outer | 2500W | 2PCS | ||
XB-OTS-6210T vertical( unified control each shelf) | 560×640×600 inner 720×820×1750 outer | 3500W | 3PCS | ||
Vacuum range | 0Pa~105Pa | ||||
Power | 220V 50Hz | ||||
Temperature resolution/ volatility | 0.1℃/±0.5℃ | ||||
Temp Range （℃） | RT+10～250℃ | ||||
Features:
The cuboid studio is made of high quality stainless steel plate to ensure durability. Toughened, bulletproof double glazing doors observe objects in the studio at a glance. The closing tightness of the box door can be adjusted, and the silicone rubber door sealing ring is integrally molded to ensure high vacuum in the box. Storage, heating, testing and drying are carried out in an oxygen-free or inert gas-filled environment, so they do not oxidize. Microcomputer intelligent temperature controller, with setting, measuring temperature double digital display and PID self-tuning function, accurate and reliable temperature control. The ratio of heating power can be adjusted arbitrarily, so as to ensure the low end temperature and temperature.
Details Images
Automatic control of vacuum degree：
The vacuum drying box adopts analogue engineering digital technology to control the vacuum, and manual control has long been a history. Do you also think that the manual lever operated valve can accurately control the vacuum degree in twenty-first Century? Through the solenoid valve fully automatic digital control of the vacuum, to provide you with more accurate and effective vacuum control. Through the panel, the vacuum degree is adjustable from 0Pa to 105Pa with adjustable precision of 1pA. The sensor uses resistive silicon tube pressure sensor, so as to ensure a stable pressure value, not affected by the air flow, the stable pressure value to the vacuum controller LED display screen. With the corresponding high power vacuum pump, the minimum vacuum in the vacuum box can reach the level of 10Pa below military level.
For higher, larger, or temperature requirements, vacuum requirements, please contact us, will be able to meet your requirements.
For higher, larger, or temperature requirements, vacuum requirements, please contact us, will be able to meet your requirements.
Advantage
Ø 24 hours online
Ø 35 years experiences
Ø Sample chamber of each model
Ø Best price, fast delivery
Ø OEM,ODM
Ø Oversea offices
Ø Own import and export business license
ØISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
Ø 35 years experiences
Ø Sample chamber of each model
Ø Best price, fast delivery
Ø OEM,ODM
Ø Oversea offices
Ø Own import and export business license
ØISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
Customer Support Services
Ø Installation
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
Ø Training (Training customer employees)
Ø Calibration
Ø Preventative maintenance
Ø Replacement parts
Ø Assistance via phone or internet
Ø On-site diagnosis and repair/online diagnosis and repair
Product packaging
Company Profile
Dongguan Xinbao Instrument Co., Ltd
Anual sales over 1,500,000USD; 30,000㎡ manufacturing base, equppied with advanced machine, 120 technicians and over 50 sales engineers, Dongguan Xinbao Instrument Co., Ltd, with its self-owned brand--OTS, has been dedicating in providing professional testing equipment with top quality since its establishment in 1978.
We own sophisticated and advanced technologies in producing environmental test chambers and mechanical test machines like temp humidity chamber, thermal shock test chamber, rain and dust test chamber, salt spray chambers ,walk in /drive in test chambers, tensile testing machine, vibration test machine, other customized test euipment and so on.
We own sophisticated and advanced technologies in producing environmental test chambers and mechanical test machines like temp humidity chamber, thermal shock test chamber, rain and dust test chamber, salt spray chambers ,walk in /drive in test chambers, tensile testing machine, vibration test machine, other customized test euipment and so on.
Production process
Exhibition
Now OTS has its main production base in Dongguan, a branch in Suzhou and offices in South Asia, Europe, USA. OTS also owns an independent laboratory which exhibits all currently produced machines under CNAS calibration, so customers can check the function and quality immediately. Equipped with over 30 workers in a metal plate department, OTS is capable to produce customized shells; What’s more, OTS has enough stock to satisfy customers need in time. In the meanwhile, every machine must be examined for 3~days before shipment and with lifetime maintenance service.
FAQ
1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE
maintenance,while considering of sea transportation, we can extend 2 months for our customers.
Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE
maintenance,while considering of sea transportation, we can extend 2 months for our customers.
If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or sky video chat if necessary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after
deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after
deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
4. How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our officail website directly.
Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
We will send you operating instructions, English video by Email. Or you can download on our officail website directly.
Most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at site.
