High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine
High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine
High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine
High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine
High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine
High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine
High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine

High Stability Opening Height 380mm Max Sheet Thickness Iron 1.5mm Automatic Metal Edge Bending Folding Machine

Share on (11000006409528):


Price:$115,000.00 - $116,019.00

Quantity:


Product Overview

Description



Product Features


• CNC controlled crowning of folding beam
• CNC folder that folds upward and downward, no need to flip the material
• Comes as standard with multifold tooling, CNC controlled sheet thickness and folding center adjustment
• Folding both up and down, folding machine eliminates the need to flip material, providing time-efficient folding of complex parts using one operator
• Easy operation: Part rests on gauging system
• Also thin and flexible blanks can be easily handled
• Safe and ergonomic operation
• Energy-sapping lifting and holding of parts is eliminated
• A single person can even bend large and heavy components
• Ideal solution for users with high demands on flexibility


Product Parameter


Model
FDG32
Work Table Length
3200mm
Opening Height
380mm
Gross Energy Requirement
6KW



Max Sheet Thickness
Stainless Steel
1.5mm
Galvanized Sheet
1.5mm
Cold Plate
1.8mm
Iron
1.5mm
Aluminum
2.0mm
Bend Height Error
0.3mm
Bend Angle Error
0.75°
Size
5100*4500*1900mm
Weight
9000KG




FAQ


1. Do you have an inspection procedure for the product?
A: Yes, We have a strict inspection of product quality and packing.

2. Who are we?
A:We are based in Guangdong, China, sell to Southeast Asia(20.00%),Eastern Europe(20.00%), WesternEurope(10.00%), North America(10.00%), Northern Europe(5.00%), Central America(5.00%),SouthAmerica(5.00%),Eastern Asia(5.00%),South Asia(5.00%),Oceania(5.00%),Southern Europe(5.00%),Africa(3.00%),MidEast(2.00%). There are total about 11-50 people in our office.

3. Which payment terms you can accept?
A: We can accept flexible payment include Bank Transfer, LC, DP, West Union, Paypal, or Combination terms as negotiation.

4. Which shipping way can you provide?
A: We can provide shipping by sea, by air, by express and etc according to customer requirements.

5. How to place order?
A: When you are ready to order, please contact us for confirm the suitable solution & plan & model. What cannot be ignored is you should provide a copy purchase order to ensure that your order is processed properly.
