Factory price Maskura 3KM long range CPE point to pint stable outdoor networking 5.8 GHz waterproof wireless bridge
- Category: >>>
- Supplier: Shenzhen Maskura Technology Co. Ltd.
Share on (11000007548874):
Product Overview
Description
bridgeMKS03
5.8G 3km bridge
MKS03 is an outdoor wireless bridge designed for video surveillance of elevators , pendant towers , communities , learning, factories , orchards , breeding plants, planting greenhouses, scenic spots and other scenes; the device works in the 5.8 GHz frequency band and can provide up to 45 0Mbps. Wireless data transmission rate; built-in 12 dBi high-gain directional antenna, stronger signal penetration, outdoor point-to-point bridging distance up to 2000 meters; pole wall-mounted compatible design, can be directly installed on the wall or pole column, beautiful Generous ; can work in various outdoor environments such as wind , rain and snow .
Product Features
5.8 GHz: Wireless rate 45 0Mbps
Adopt 12dBi high gain directional antenna
Protection IP65 waterproof and dustproof
Two power supply modes are available: Ethernet port supports POE input 24V, DC interface supports input 12V
Product Specifications
Hardware Specifications |
|
|
CPU |
| RTL8881 |
storage |
| Flash: 2MB; DDR: 8MB |
wired standard |
| IEEE802.3, IEEE802.3u |
Ethernet interface |
| 10/100Mbps LAN port*1 |
antenna |
| Built-in directional antenna 12dBi |
button |
| Reset Button *1 |
Power supply |
| POE 24V or DC 12V |
panel indicator |
| LED*4 (LAN, WLAN, RSSI1, RSSI2) |
Software Specifications |
|
|
system status |
| System information, wireless information, LAN information |
Quick Setup |
| master mode |
|
| slave mode |
network settings |
| Network mode, device IP |
wireless setting |
| Tube wireless status |
|
| Basic settings (wireless switch, wireless light, frequency band, wireless password, channel) |
|
| MAC authentication |
advanced settings |
| BG Protected Mode, Transmit Power, Wi-Fi Multimedia (WMM) |
Product Specifications
Wireless Specifications |
|
|
wireless standard |
| IEEE 802.11a/n/ac |
wireless rate |
| 450Mbps |
wireless power |
| 20dBm |
Wireless Acceptance Sensitivity |
| -90dBm |
wireless band |
| 5.8GHz |
Other specifications |
|
|
Application Environment |
| Working temperature: -20℃~55℃ |
|
| Working humidity: 10%~90% RH non-condensing |
|
| Storage temperature: -40℃~80℃ |
|
| Storage humidity: 5%~90% RH non-condensing |
Product Size |
| 202*78*56mm |
Installation method |
| pole, wall mount |
Package Contents |
| MKS03 bridge pair |
|
| Two POE 24V power adapters |
|
| cable ties |
|
| Configuration manual, certificate, warranty card |
