790317 001 10GB 2 Port 562FLR SFP Adapter

Product Overview

Description

Specifications
MPN: 790317-001

Option Part Number: 727054-B21
Spare Part Number: 790317-001

General

Device Type: Network Adapter - 10Gbit Ethernet
Data Rate: Two ports, each at 20 Gb/s bi-directional; 40 Gb/s aggregate bi-directional theoretical bandwidth.
Form Factor: FlexibleLOM
Bus Type: PCI Express 3.0 (Gen 3) x8
IEEE Compliance: 802.3, 802.1ab, 802.3x, 802.3ad, 802.1p/ 802.1q, 802.3ae, 802.1Qau

Networking

Network Processor: Intel X710 Controller
Ports: 10 Gigabit SFP+ x 2
Connectivity Technology: Wired
Data Link Protocol: 10 GigE
Data Transfer Rate: 10 Gbps
Capacity: Jumbo frame size: 9.5 KB
Status Indicators: Status, link/activity
Features: Wake on LAN (WOL), PXE support

Expansion & Connectivity

Interfaces: 2 x 10Gb Ethernet - SFP+

Processor / Memory

Processor: 1 Intel (Intel X710 Controller)

Power Specifications

Power Consumption: 12 Watt

Product Dimensions & Weight

Width: 9.50 inch
Height: 2.25 inch
Depth: 7.50 inch
Weight: 1.00 lbs
