6 Inch Deep Well Water Submersible Pump Cast Iron Pumps DP630B Type Best Quality Factory Sale Submersible Pumps
- Category: >>>
- Supplier: INNTURK DIJITAL PAZARLAMA ITHALAT IHRACAT SANAYI VE TICARET LIMITED SIRKETI
Share on (11000007858948):
Product Overview
Description
Product Description
Specification
item | value |
Warranty | 2 Years spare parts guarantee |
Customized support | OEM |
Brand Name | INNTURK or your brand |
Model Number | INNDP630-MX-b |
Place of Origin | Turkey |
Sanliurfa | |
Application | Other, Irrigation and Agriculture, Water Distribution, Seawater Transport, Geothermal Wells, Agricultural watering, Agricultural irrigation, Drinking Water Wells, City Networks |
Horsepower | 5.5-50 HP |
Power Source | Electric |
Pressure | High Pressure |
Structure | Multistage Pump |
Outlet Size | 150mm |
Voltage | 380V-415V |
motor | Excluding (Motor priced separately) |
Product name | Submersible Pump |
Usage | Water |
Material | Cast Iron |
Theory | Multi Stages Pump |
Type | Watering |
Pump Type | Deep Well Pump |
Standard or Nonstandard | NEMA Standard |
Frequency | 50/60 Hz |
Number of the vane | 6 |
Max. water temperature | 35° C (50° C optional) |
Submersbile Pump Cast Iron 6 inch INNDP630b
Technical Specifications
Frequency: 50 Hz
Outlet connection diameter: 3" (inside gear)
Max. sand content: 50 gr / m
Pump outside diameter: 150 mm
Number of the vane: 6
Degree of protection: IP 68
Voltage: 380-415 V (+%6 / -%10)
Direction Of Rotation: Counter-clockwise
Max. water temperature: 35º C (50º C opsiyonel)
Diffuser: Cast Iron (GG22-GG25)
Impeller: Cast Iron (GG22-GG25)
Pump shaft: Stainless steel (AISI 420)
Coupling: Stainless steel (AISI 420)
Strainer: Stainless steel (AISI 304)
Valve cap: Cast Iron (GG22-GG25)
Connection: Based on NEMA standarts
Area of Use
Water supply
Drinking-water wells
Agrycultural irrigation
Geotermal wells
Sea water transfer
Specifications
Cast iron pumps are economic and efficient
Cast iron submersible pumps are designed to operate with clean water.
The body and fan materials are available as standard GG22 material
By request it can be made from special materials
Technical Specifications
Frequency: 50 Hz
Outlet connection diameter: 3" (inside gear)
Max. sand content: 50 gr / m
Pump outside diameter: 150 mm
Number of the vane: 6
Degree of protection: IP 68
Voltage: 380-415 V (+%6 / -%10)
Direction Of Rotation: Counter-clockwise
Max. water temperature: 35º C (50º C opsiyonel)
Diffuser: Cast Iron (GG22-GG25)
Impeller: Cast Iron (GG22-GG25)
Pump shaft: Stainless steel (AISI 420)
Coupling: Stainless steel (AISI 420)
Strainer: Stainless steel (AISI 304)
Valve cap: Cast Iron (GG22-GG25)
Connection: Based on NEMA standarts
Area of Use
Water supply
Drinking-water wells
Agrycultural irrigation
Geotermal wells
Sea water transfer
Specifications
Cast iron pumps are economic and efficient
Cast iron submersible pumps are designed to operate with clean water.
The body and fan materials are available as standard GG22 material
By request it can be made from special materials
Company Profile
Before purchase, you can visit our factory in Sanliurfa, Turkey.
We are ready to make a dealer distributor and service agreement in your country.
1. Who are we?
Located in Turkey, INNTURK Global Trading is an autonomous trading company with internet distributorship in an organized industrial zone where there are more than 450 manufacturers. You can supply high quality wholesale products at affordable prices fast and safely from Turkey which is at the center of all commercial networks.
2. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final Inspection before shipment.
3. Why should you buy from us not from other suppliers?
- We are in Turkey which is at the center of all commercial networks.
- We are only a few hours away from the commercial port and this saves your logistics costs.
- We are with more than 450 manufacturers and this gives you the opportunity to supply a wide range of products.
- We offer the possibility of production with your own brand.
- Due to the government incentives provided to our region, the production costs are low and this allows you to buy high quality products at affordable prices.
1. Who are we?
Located in Turkey, INNTURK Global Trading is an autonomous trading company with internet distributorship in an organized industrial zone where there are more than 450 manufacturers. You can supply high quality wholesale products at affordable prices fast and safely from Turkey which is at the center of all commercial networks.
2. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final Inspection before shipment.
3. Why should you buy from us not from other suppliers?
- We are in Turkey which is at the center of all commercial networks.
- We are only a few hours away from the commercial port and this saves your logistics costs.
- We are with more than 450 manufacturers and this gives you the opportunity to supply a wide range of products.
- We offer the possibility of production with your own brand.
- Due to the government incentives provided to our region, the production costs are low and this allows you to buy high quality products at affordable prices.
