CNC Slant Bed Lathe Machine TCK400GP Metal Turning Lathe For Sale

Product Overview

Description

Specifications	TCK400GP
Max.swing over bed (mm)	Φ500
Max.turning diameter (mm)	Φ500
Max.swing over cross slide (mm)	Φ230
Max.turning length (mm)	520
Spindle nose	A2-6
Chuck size	8”
Spindle motor power (kw)	11-15
Max.spindle speed (rpm)	4200
Spindle bore (mm)	Φ66
Max turning Dia Bar (mm)	Φ52
X/Z axis leadscrew (mm)	32/40
X axis limit Travel (mm)	270
Z axis limit Travel (mm)	610
X/Z axis motor torque (N/m)	11/11
X/Z axis linear guideway (mm)	45/45
X/Z axis accuracy (mm)	0.008
X/Z axis repeat accuracy (mm)	0.005
Tailstock quill diameter (mm)	Φ80
Tailstock quill travel (mm)	80
Tailstock travel (mm)	480
Tailstock taper	MT5
Machine dimension (mm)	4200X2000X2450
Weight (kg)	4000

Standard accessories:

Fanuc 0i TF Control system

Drive servo motors from Fanuc

Spindle motor CTB

Hydraulic 3 jaw chuck from Taiwan

Hydraulic tail stock

12 stations servo hydraulic turret

Chain type chip conveyor
Air conditioner in cabinet

Schneider eletronic components

Ball leadscrew PMI

Bearings for X,Z : FAG-P4

MPG

Cutting Cooling system

Work lamp

Central auto-lubricating system

Tri-color warning lamp

Heat exchanger in cabinet

Full closed guard

Tools and tool box

Leveling bolts and blocks

Optional accessories:

Live center

Spindle bearings from NSK

Renishaw measuring arm

Power turret with Y axis from Taiwan

Power head + Radial power head

Hydraulic steady rest

Hydraulic tailstock programming

Tailstock hydraulic moving (R axis)

Tailstock with leadscrew and linear guideway (R axis)

 X,Z axis linear guideway Roller type
