Self Loading Pallet Stacker Smartline Electric Forklift Truck
- Category: >>>
- Supplier: MM Immo Solution GmbH
Share on (11000008304401):
Product Overview
Description
Manufacturer | VMAX | |
Model | Unit | CPCD35 |
Power type | Diesel | |
Rated capacity | kg | 3500 |
Load center | mm | 500 |
Operator type | mm | Drive in seat |
Max. lift height of mast with Load-backrest | mm | 4262 |
Max.lift height of fork(standard) | mm | 3000 |
Height of mast (standard) | mm | 2180 |
Free lift height(standard) | mm | 170 |
Height of Load-backrest | mm | 1235 |
Distance from seat to overhead guard | mm | 1000 |
overhead guard height | mm | 2090 |
Length with fork | mm | 2693 |
Front overhang | mm | 498 |
Rear overhang | mm | 495 |
Wheel base | mm | 1700 |
The height of traction pin | mm | 310 |
Min. ground clearance | mm | 135 |
Overall width | mm | 1225 |
The distance between forks | mm | 1060/250 |
Tread(front /rear) | mm | 1000/970 |
Min. Turning radius(outside) | mm | 2400 |
Min. Turning radius(inside) | mm | 200 |
Min. Intersecting aisle | mm | 2400 |
Mast tilt angle | deg | 6° / 12° |
Fork size | mm | 1070X125X45 |
Max.Drive speeds(with/without load) | km/h | 19/19 |
Lifting speeds (with load) | mm/s | 330/370 |
Lowering speeds(with /without full load) | mm/s | 350/400 |
Max. tractive force | KN | 20/16 |
Max.grade ability (with/without full load) | % | 15/20 |
Total weight | kg | 4700 |
Weight Distribution full load (front/ rear) | kg | 7380/820 |
Weight Distribution zero load(front / rear) | kg | 1880/2820 |
