3034572 Engine Spare Parts Diesel Speed Sensor 3034572 3655944

Share on (11000009371369):


Price:$8.00 - $11.00

Quantity:


Product Overview

Description


Speed Sensor 3034572









Product Description




3034572

Diesel Engine Magnetic Pickup MPU Speed Sensors 3034572 indicates when ring gear teeth, or other ferrous projections,pass the tip of the sensor.Electrical impulses are induced within the coil and sent to speed control unit.The signal from the magnetic speed sensor,teeth per second is directly proportional to engine speed.










































3034572



Range


50-5000hz


Inductance Value


42mh + 25%


Resistance Value


300 ohms maximum


Thread


5 / 8-18 unf-2a


Distance from Tooth


028 in min. -. 042 in max


Temperature Range


- 55 to 105


Idle Output


1.5 volts AC minimum


Output


30 volts AC
