Product Overview
Description
Brand New 17m Insulated aerial work vehicle truck chassis + insulated arm/bucket with good price
Product Description
1. Work Bucket: Work bucket size is 1.20.61.05 m, with steps for easy
entry and exit, equipped with buffered work bucket support
2. Personal Safety System: Seat belt ring provided, the hook anchor to
the work bucketsupport.
3. Lower Control: The control valve on the turntable controls the full
functions of the arm, equipped with a selection valve for emergency
stop control.
4. Upper Control: The upper control includes a 3D valve to prevent
misoperation.arm movement is controlled by the 3D valve
handle.The upper control is provided with an emergency stop control
·and a hydraulic tool selection control.
5. Work Bucket Rotator: The work bucket rotator can spin the work
bucket from one side of the expansion arm assembly turn 180 ° to
the other side of the expansion arm assembly.
Maximum working height............................................................. 17.3m
Maximum operating range............................................................... 11.2m
Insulation length of the upper arm (All shrinkage)........................ 1.03m
Insulation length of the upper arm (All extended)........................ 4.61m
Insulation length of lower arm....................................................... 0.61m
Pressure resistance level............................................................. ≤35kV
Telescopic boom elevation angle
-19°~+85°
Lower arm elevation angle..................................................... 0°~+85°
Upper with the rotation angle............................................................ 360°
Rotation angle of working bucket
180°(±90°)
Working pressure........................................................................15.8MPa
Hydraulic pressure system..............................................................Open
Power supply...................................................................................PTO
Maximum load of working bucket................................................. 272kg
Maximum load of work bucket (When installing small crane)...... 227kg
Maximum load of small crane (Optional).......................................454kg
| Maximum working height | 17.3m |
| Maximum operating range | 11.2m |
| Insulation length of the upper arm (All shrinkage) | 1.03m |
| Insulation length of the upper arm (All extended) | 4.61m |
| Insulation length of lower arm | 0.61m |
| Pressure resistance level | ≤35kV |
| Telescopic boom elevation angle | ’-19°~+85° |
| Lower arm elevation angle | 0°~+85° |
| Upper with the rotation angle | 360° |
| Rotation angle of working bucket | 180°(±90°) |
| Working pressure | 15.8MPa |
| Hydraulic pressure system | Open |
| Power supply | PTO |
| Maximum load of working bucket 272kg | 272kg |
| Maximum load of work bucket (When installing small crane) 227kg | 227kg |
| Maximum load of small crane (Optional) | 454kg |
| Chassis | FTR |
| Isuzu 4HK1-TC50 engine,205 hp, MLD six-speed transmission, AC, steering assist, central control lock, electric doors and windows, front axle 6.3 tons, rear axle 13 tons, with ABS. Standard 1000R20 tires. Air brake. 4500 Wheelbase, Model |: QL1160VMFRY |
