Product Overview

Description



Product Description


molded case circuit breaker is suitable for DC systems with rated working DC voltage below 1000V and rated working current up to 10A-1250A. The circuit breaker has protection functions such as overload, short circuit and under voltage, which can protect lines and power supply equipment from over-voltage damage due to overvoltage and overcurrent. Widely used in power generation, power transmission and transformation, new energy, communications, construction and other fields.


Features


Features
* Operating full load at 50℃
* The breaker has isolation function,
* lEC60947-2 and GB14048.2 standards
* Breaker can be mounted vertically, or in horizon
* Used in DC system with no earthing, one pole earthed, or neutral point earthed
* Maximum carry 1250A at several breakers operated in parallel.
* Arcing quench system integrates VJC and lSTAC technologies




Specification


Parameter
Value
Shell frame grade current
250
Ripping device rated current
100、125、140、160、180、200、225、250
Number of poles
4
Rated insulation voltage
1000V
Rated operational voltage
DC 1000V
Rated impulse withstand voltage
8000V
Rated ultimate short-circuit breaking capacity
40
Rated operational short-circuit breaking capacity
25
Mechanical life
10000
Electrical life
5000
Flashover distance
≯50
Dimension
142X165X103mm
Overload protection
250-630 A
Protection function
100-250 A
250-360 A
Action tolerance
±20%
Work environment
-40℃~+70℃


Note: If you have any puzzles or requests about this product (including model number, data sheet or any other aspects), please contact us immediately.


Application


* In medium and low voltage power system
* Protect circuits from overload, short circuit and other faults
* In industrial control system
* Protect motors, transformers and other equipment
* Used in household, commercial and industrial building electrical
* Used to protect communication equipment, communication lines, etc.
* Electrical system of new energy equipment such as solar energy and wind energy
* Guarantee the safe operation of electrical equipment
