Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available
Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available
Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available
Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available
Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available
Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available
Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available

Cat Backloe Loader 4WD and Used Backhoe Loader for sale Mini Backhoe loader with all parts available

Share on (11000009580368):


Price:

Quantity:


Product Overview

Description




































































































































































































The specification of 2.5ton backhoe loader 388 Mini Excavator



Transport Dimension


Overall Operating Weight


8200KG


mm L*W*H


6230×2365×3752


Wheel base


2200mm


Min. Ground Clearance


300mm


Bucket Capacity


1.0m3


Breakout Force


38KN


Loading Lifting Capacity


2500KG


Bucket Dumping Height


2650mm


Bucket Dumping Distance


1025mm


Digging Depth


52mm


Backhoe Capacity


0.3 m3


Max. Digging Depth


4085mm


Swing Angle of Excavator Grab


190o


Max. Pulling Force


39KN


Engine


Model


YC4A105Z-T20


Type


turbocharging four-stroke


Cylinder-Inside Diameter*Stroke


4—105


Rated Power


75KW/100HP


Rated Speed


2400r/min


Min. Fuel Consumption


235g/kw.h


Max.Torque


310NM


Displacement


4.3L


Steering System


Model of Steering Device


BZZ5-250


Steering Angle


±36 o


Min. turning radius


6581mm


Pressure of the system


12Mpa


Axle


Manufacturer


Feicheng Axle Factory


Main Transmission Type


Double Reduction


Final Reducer


Single Stage Final Reducer


Rated Loader of Axle


4/18.5t


Transmission System


Torque Converter


Model


YJ280


Type


Single-stage Three Elements


Max. Efficiency


84.40%


Inlet Pressure


0.4Mpa—0.55 Mpa


Outlet Pressure


1.2Mpa—1.5 Mpa


Cooling Method


Oil-cooling Pressure Circulation


Gearbox


Type


Fixed Shaft Power Transmission


Oil Pressure of Clutch


1373Kpa—1569 Kpa


Gears


Two Gears Ahead, Two Gears Astern


Max.Speed


22Km/h


Tyre


Model


14-17.5/19.5L-24


Pressure of Front wheel


0.22 Mpa


Pressure of Back Wheel


0.22 Mpa



2 (1).jpeg2 (1).jpg2 (2).jpeg2 (2).jpg2 (10).jpg2 (11).jpg2 (12).jpg2 (14).jpg
