Product Overview

Description

Biomass Pellet Burner with Back Boiler for Central Heating – Hot Water, Suitable for un-vented heating system



  3 Heat Output Settings:
  Maximum Water Heat Output: 19kw / Space Heating Output: 4kw
  Nominal Water Heating Output: 16.11kw /Space Heating Output: 2.1kw
  Reduced Water Heating Output: 3.93kw /Space Heating Output: 1.16kw
  Programmable Daily and Weekly Timer / Clock via Digital Display Panel
   Three Ignitions and Three Shutdowns for Each Day of the Week
·  Dimensions: W625mm / D640mm / H1214mm
   Combustion Chamber Dimensions: Height 356mm x Width 300mm x Depth 165mm
   Power Supply: 240v
· Weight: 255kg NB. This is a very heavy item, doorstep delivery only.
· Colour: Dark Grey and Red
· Flue Diameter: 80mm
· Features:- Eco Design 2022 Certified, Touch Screen Control Panel, Large Ceramic Glass Window – Air wash – Clean Burning – Large removable Ash Container, Large 26 litre pellet store, Reserve pellet store, Back Boiler Suitable for Pressurised heating systems – Vented or Un-vented, Digital Display Panel, Integrated Circulation Pump and Safety Expansion Vessel,  50mm Direct Air Supply Connection, Auto Cut off at 90 degree water temperature
· Flue Outlet: Rear – 80mm Diameter
2 x 3/4 inch BSP male Water Connection Ports – Flow and Return, and integrated 3 bar pressure release valve
· Efficiency: 92.1% – A+ Rated
· Fuel: Biomass Pellets
· Warranty: 2 years (NB The ignitor carries a 6 months warranty,



The  Biomass Pellet burner offers highly efficient room and water heating as well as being stylish in it appearance. It offer offers a maximum output of 21kw with an outstanding efficiency rating of over 92%.

Bio Mass Pellet burners offer a credible alternative to conventional fossil fuel powered heating appliances. The  pellet burner will automatically ignite / fire and operate in accordance with timed settings that are pre set through the touch screen control panel.

designed to heat water for central heating and domestic hot water. The pellet stove burns wood pellets, which are made from sustainable grown, raw material with an excellent ecological balance. The pellets are designed to  release the minimum of harmful emissions and are also cheaper and more efficient than conventional fossil fuels.

 designed to offer fully automated operation and incorporates a fully programmable control system to offer a daily, or weekly program, which can include up to three ignitions and three shutdowns for each day of the week. In addition it offers 3 different heat output settings to allow all year round use i.e. Maximum Output, Nominal Output and Reduced Output. The maximum output offers 19kw to water heating and 4kw to room heating, the nominal output offers 16.11kw to water heating and 2.16kw to room heating, whilst the reduced output offers 3.93kw to water heating and 1.16kw to room heating.

Product parameters(HY-6A-1)
Dimension(W*H*D)			463*718*507mm
Weight			70kg
Air inlet Pipe			50mm
Air outlet Pipe			80mm
Heat Area			60m
Automatic Burning Time(Min-Max)			13-27 h
Fuel			Wood Pellet
Consumption for Pellet(Min-Max)			0.6-1.2 kg/h
Efficiency			90%
Hopper Capacity			16kg
Electronic comsuption			100-400 W/h
Rating Valtage and Frequecy			230/50 V/HZ
