Yanmar Engine Skid Steer Loader 3 Ton Rated Load for Farms Skid Steers 316GR 318G 324G 330G Models

Product Overview

Description

Product Description


    316GRSkid Steer

    Gross Power: 48.5 kW (65 hp)
    Net Power: 45.6 kW (61 hp)
    Rated Operating Capacity: 795 kg (1,750 lb.)
    Operating Weight: 2806 kg (6,180 lb.)

Export to Excel
DESCRIPTION
Lift Geometry   : Radial
DRIVELINE
Engine Manufacturer    :Yanmar
Engine Model    :4TNV86CHT
Aspiration   : Turbocharger
Displacement, ltr (Inches³)   : 2.1 (128)
Rated Speed, rpm   : 2600
SAE Net Power, kW (hp)    :45.6 (61)
SAE Gross Power, kW (hp)    :48.5 (65)
Max. Gross Torque, Nm (lbf / ft)    :207 (153)
Tire size - Standard    :10 - 16.5
DIMENSIONS
Length - No Bucket, mm (inches)    :2630 (103)
Length - With Bucket Foundry, mm (inches)   : 3240 (127.6)
Width - No Bucket, mm (inches)    :1600 (62.9)
Overall Height, mm (inches)    :1960 (77.2)
Ground Clearance, mm (inches)    :180 (7)
Wheelbase, mm (inches)    :1050 (41.5)
Rear Departure Angle, Degrees   : 22.3
Height to Hinge Pin, mm (inches)    :2920 (115.1)
Dump Angle, Degrees   : 45
Dump Height - Maximum Foundry, mm (inches)    :2250 (88.6)
Reach - Max Dump Height Foundry, mm (inches)    :400 (15.8)
Rollback - Ground Level, Degrees    :30
CAPACITIES
Fuel Tank, ltr (gallons (US))   : 71 (19)
PERFORMANCE
Rated Operating Capacity - Foundry, kg (lbs)    :795 (1750)
Tipping Load - Foundry, kg (lbs)    :1589 (3500)
Speed - Maximum, kph (mph)   : 11.1 (6.9)
Breakout - Lift Foundry, kN (lbf)    :21.1 (4750)
Breakout - Bucket Foundry, kN (lbf)   : 23.3 (5250)
Hydraulic Power, kW (hp)    :24.729 (33.1)
Pump Output, lt/min (gallons (US) / min)   : 63 (17)
System Pressure, bar (PSI)   : 237.87 (3450)
WEIGHTS
Operating Weight - Foundry, kg (lbs)   : 2806 (6180)
Show Less
Our Services


Two-Year/2,000-Hour Full-Machine Standard Warranty
Packaging & Shipping



Package Size
349.00cm * 173.00cm * 215.00cm
Package Gross Weight
2400.000kg
