Двойной насос с зубчатой передачей тандем зубчатый насос, гидравлический насос с зубчатой передачей для
- Category: >>>
- Supplier: Jiashan Jiuyuan Precision Tooling Co. Ltd.
Share on (1100015000648):
Product Overview
Description
Product Parameters
SKU: LSPV-002
Model | Name | Description | Attachement | Options |
GP-001 | Aluminum Body Gear Pump, 2 Bolt | High mechanical and volumetric efficiency, low noise. Applicable to lifting machinery, mine and agricultural equipment and more. | Shaft: 1/2” w/ flat key Inlet: 3/4”-16 SAE ORB Outlet: 9/16”-16 SAE ORB Mount: 2 bolt, 3.25” apart | 3.25 gpm @ 2000rpm, 4000 psi |
GP-002 | Aluminum Body Gear Pump, 4 Bolt | High mechanical and volumetric efficiency, low noise. Applicable to lifting machinery, mine and agricultural equipment and more. | Shaft: 1/2” w/ flat key Inlet: 3/4”-16 SAE ORB Outlet: 9/16”-16 SAE ORB Mount: STN 4 bolt, 2” square | 2.1 gpm @ 2000rpm, 4000 psi |
GP-003 | Bidirectional Gear Pump, 2 Bolt | Bidirectional ability lends itself well to closed hydraulic circuit applications, changes flow direction without needing directional valves | Shaft: 5/8” w/ flat key Inlet: 1-1/16”-12 SAE ORB Outlet: 7/8”-14 SAE ORB Mount: 2 bolt, 3.25” apart | 6.1 gpm @ 2000rpm, 4000 psi 9.2 gpm @ 1500rpm, 3200psi |
GP-004 | Bidirectional gear Pump, 4 Bolt | Bi directional gear pump, equipped with 2 check valves. Operates CW and CCW. | Shaft: 1/2” w/ flat key Ports: 9/16”-18 UNF Mount: 4 bolt, 2” square pattern | 1.6 gpm 2.1 gpm @ 3600rpm, 4000 psi 4 gpm @ 3600 rpm, 3000 psi |
GP-005 | Small Gear Pump w/ Valves, 4 Bolt | Equipped with relief valve and check valve. Lends itself well to power up – gravity down circuits in combination with a 2/2 release valve. | Shaft: 1/2” Tang Inlet: 3/4”-16 SAE ORB Outlet: 9/16”-18 SAE ORB Mount: 4 bolt, 2” square 2 Bolt, 3.25” apart | 1.1 GPM @ 2000rpm, 1740 psi |
GP-006 | Snowplow Gear Pump, 4 Bolt | High mechanical and volumetric efficiency, low noise. Widely used in snow plow power units. CCW rotation. No valves. | Shaft: 7/16” Tang Inlet: 5/8” Outlet: 3/8” Mount: 4 Bolt, 2” square | 0.95 GPM @ 2000rpm, 1740 psi |
GP-007 | Rotary Gear Flow Divider | Flow dividers used with a single pump can be used to: operate multiple cylinders or motors; divide pump output to multiple circuits; amplify pressure to greater than pump capacity. | Ports: For -42 & -88:7/8”-14 SAE For -21:3/4”-16 SAE | 2 section, 3600psi 6.8 gpm 14 gpm 4 section, 3000psi 6.8 gpm 14 gpm |
Details Images
Application
Company partners
Customer Feedback
Company Profile
FAQ
1. What do you do? - Our products mainly include: Hydraulic jacks, Engine Stand, Jack Stand, Auto Repair Tools, etc. 2. Can you do OEM for us ? - We accept OEM products. Your brand, logo, label is welcomed. 3. Can you help us to do some change about your product? - Yes, special drawing and design will be evaluated by our technical department, unit cost will be calculated by finance department for your final confirmation. All procedures will be informed and confirmed with you in advance. 4. Can I get a sample? - Yes. Samples are welcome to us before mass production. But few extra cost and products cost will be charge from customer first, and sample cost will be back to customer once started mass production. 5. Where is your company location? - We’re in Jiaxing city Zhejiang Province, where is by train to Hangzhou, Shanghai and Suzhou 30 minutes respectively. The most convenient traffic location around SHANGHAI area. Welcome to visit our factory!
