Features
1) Module efficiency : 16%
2) Warranty : 12 years/90%,25 years/80%, guaranteed 10years material and workmanship
3) Tolerance : Guatanteed tolerance,different model with diffetent tolerance,and delivers higher outputs reliably
4) Excellent performance under low light conditions
5) Module certified to wind and snow loads
6) Anti-reflective,hydrophobic layer with light absorption and minimal surface dust
7) Rich selection of solar power
| Electrical Characteristics | ||||
| STC (Irradiance 1,000W/m2, module temperature 25℃, AM=1.5) | OL90M-10 | |||
| Rated Power (Pmax) | 90W | |||
| Voltage at Pmax (Vmp) | 18.1V | |||
| Current at Pmax (Imp) | 5.15A | |||
| Warranted Minimum Pmax | 100W | |||
| Short-Circuit Current (Isc) | 5.43A | |||
| Open-Circuit Voltage (Voc) | 21.6V | |||
| Module Efficiency | 19.00% | |||
| Operating Module Temperature | -40℃ to + 85℃ | |||
| Maximum System Voltage | 1,000V(IEC) / 1,000V(UL) | |||
| Maximum Series Fuse Rating | 10A | |||
| Maximum Reverse Current | 20.25A | |||
| Power Tolerance | 0 ~ +5 W | |||





FAQ:
Q1 Are you a factory or trading company?
A Yes, we are factory, supplying OEM/ODM service.
Q2 Can you accept OEM service?
A Yes, we can. Qty is not the only standard , more qty, less cost.
Q3 How about your after sales-service?
A 1.Guarantee time: one year, but solar panel 10 years
2.Spare parts:1% spare parts will be shipped with your order.
Q4 How about your payment terms?
A We accept T/T, LC
Q5 What certification do you have?
A 1.CE, 2.According to your need , do the certification or report , if you have a big order.
Q6 How many day about delivery time?
A 1.Sample delivered in 3-5 days.
2.Order delivered in 15-20 days.
Q7 Which port shipping goods?
Ningbo port/ shanghai port/yiwu port
