JIUWU Factory Customization Alumina tube porous ceramic membrane Price Concessions
- Category: >>>
- Supplier: Jiangsu Jiuwu Hi-Tech Co. Ltd.
Share on (1120782750):
Product Overview
Description
Product Description
Ceramic membrane | Model | CMF37036-1200mm-200nm |
Raw Material | α-Alumina/Zirconia | |
Pore size | 200 nm | |
Length | 1200 mm | |
Membrane area | 0.5 m2 | |
Outside diameter | 40 mm | |
Channel Diameter | 3.6 mm | |
Channel Qty | 37 | |
Gross Weight | 2.5 kg | |
Construction | Multi-channel tubular element | |
| ||
Operating conditions | Typical Operating Pressure | 29-145 psi (2-10 bar) |
Maximum Operating Temperature | 302°F (150°C) | |
Maximum Cleaning Temperature | 176°F (80°C) | |
Allowable pH - Continuous operation | 0-14 | |
Allowable pH - Clean-In-Place (CIP) | 0-14 | |
| ||
Application area | Food & Beverage | |
Bio- pharm | ||
Chemical & Petro- Chemical | ||
Water & Wastewater treatment | ||
Packaging & Shipping
Destination | Express delivery | Air cargo and ship cargo |
America | √ | √ |
Europe | √ | √ |
Southeast Asia | √ | √ |
Africa | √ | √ |
Company Information
JIANGSU JIUWU HI-TECH CO.,LTD (referred to as "JIUWU HI-TECH") was founded in 1997. In 2017, JIUWU HI-TECH has listed on Shenzhen stock exchange (stock code: 300631). Now it becomes the largest ceramic membrane manufacturer in the world.
FAQ
What is the real material for producing ceramic membranes?
Ceramic membrane elements are manufactured from pure α-Al2O3, the chemical stable form of Al2O3. Membranes are made of Al2O3, ZrO2 or TiO2depending on pore size. Due to fine nuanced manufacturing steps, pore sizes can be achieved covering the whole range of micro- and ultra filtration as well as nano filtration. The tube shaped mono- and multi channel filter elements are suitable for applications under abrasive and chemical aggressive conditions. The high temperature resistance offers use in furthermore interesting
applications.
