Product Overview
Description
D5 / 1.2601 die steel
1 tool steel Cr12MoV
2 100% manufacturer, first forge, then hot roll to save material
3 anneal delivery
chemical composition
| C | Si | Mn | Cr | Mo | V | AISI | DIN | JIS | |
| Cr12MoV | 1.45~1.70 | ≤0.40 | ≤0.40 | 11.00~12.5 | 0.4~0.6 | 0.15~0.3 | ----- | 1.2601 | SKD11 |
Regular specifications :
Flat steel (thicknessX width)mm | hot-rolled,forging round bar (mm) |
12-70x155-610 | 12-280 |
characters:
The steel is of hign hardenability, and not hardening crack distorted easily after hardened.
The steel is of fine hardness and abrasive resistance
application :it is a suitable material for making all kinds mould which has large cross section, complex shape and bear heavy shock such as cold cutting scissors, trimming mould,measuring tools etc
Size
| Round | Diameter | Length | |
| 5mm-500mm | 2000mm-5800mm | ||
| Steel plate | Thickness | Width | Length |
| 5-400mm | 80-1000mm | 2000mm-5800mm | |
Pre-heat treatment
1.Annealing after forging:heat temperature 850-870°c,keep temperature 1-2H,furnace cold below 500,out and air cool,hardness is 207-255HBS
2.Isothermal after forging:heat temperature 850-870°c,keep temperature 1-2H,furnace cold 720-750°cm,keep temperature 3-4H,furnace cold below 550°c ,out and air cool.hardness is 207-255HBS
3.High temperature tempering:heat temperature 760-790°c,keep 2-3H,furnace cold and air cool,hardness is 207-255HBS.
Characteristic
1.High toughness and abrasion resistance.
2.Good mechnical property
3.Large deformation resistance
Application
Make different die ,like heading die,buzz-saw,edge mould,plate deep drawing die etc
