Sedelon Oil and Gas High Pressure 1500lb cast stainless steel WCB hand wheel steel flanged connection globe valves

Product Overview

Description

Sedelon Oil and Gas High Pressure 1500lb cast stainless steel  WCB hand wheel steel flanged connection globe valves

Applicable standards

STEEL GLOBE VALVES BS 1837/16.34

STAINLESS STEEL GLOBE VALVES, API 603

STEEL VALVES, ASME B16.34

FACE TO FACE, ASME B16.10

END FLANGES, ASME B16.5

BUTTWELDING ENDS, ASME B16.25

INSPECTION AND TEST, API598



Design descriptions:

FULL PORT DESIGN

PSB, PRESSSURE SEAL BONNET

STRAIGHT PATTTERN BODY DESIGN

OS&Y, OUTSIDE SCREW AND YOKE

BB, BOLTED BONNET

YOKE INTEGRAL WITH BONNET

RISING STEM AND HANDWHEEL

LOOSE DISC, CHOICE OF PLUG OR BALL

RENEWABLE SEAT RING

IMPACT HANDWHEEL FOR 10’’ & ABOVE

HORIZONTAL SERVICE

FLANGED OR BUTTWELDING ENDS

AVAILABLE WITH BEVEL GEAR OPERATOR



Manufacturing Range

Size: NPS 2’’~24’’

Pressure Rating: Class 150Lb~2500Lb

Material: WCB,WC6,WC9,CF8,CF8M,CF3,CF3M,4A,5A,6A,CN7M,LC1 LC2, LC3, LCB, LCC, Monel,  C95800, C95500,etc

Design & Manufacturing Standard: API 603, BS16.34, ASME B16.10, ASME B16.5

Face to face: ASME B16.10

End Connection: ASME B16.5, ASME B16.25

Test and Inspection:API598

Operation Method:Manual, Bevel Gear, Gear, Electric Actuator, Pneumatic Actuator











Feature

Size:Various

Certificate:TS,ISO,API,CE

Medium:Water,steam,oil,strong base and so on

Application: used in large diameter (LV) air,gas pipes road and water routes



Advantage:

Professional: We are professional manufacturer of valves.Ensure our valves is quality controlled and reliable.

Quality Control: We have been engaged in valve design for many year and can guarantee best quality

Experienced Sales Team: Our sales team is experienced, and they all know our product well.

About Price: we provide very reasonable and competitive price for you



Our Capacity:

1)Date of foundation:2008

2)Total Revenue:Above $100 million

3)About QC: Excellence, quality first is our philosophy

4)Sales Market: Southeast Asia and other Overseas markets

5)Main Products: Gate Valves, Ball Valves, Check Valves, Butterfly Valves, Globe Valves, and Plug Valves
