Product Overview
Description
Dot Matrix Display VFD35-2501FA Display Screen
25Grid x 35Anode 3Color
Cadmium Free Phosphor, Lead Free solder
Color of llumination: Reddish Orange
Yellow
Green
Outer Dimension: 150*35*8.5 mm
Lead Pitch: 2.0mm
Lead Out: Double Bending Pin
Operating Temperature: -20----+70 °c
Storage Temperature: -55----+80 °c
Cadmium Free Phosphor, Lead Free solder
Color of llumination: Reddish Orange
Yellow
Green
Outer Dimension: 150*35*8.5 mm
Lead Pitch: 2.0mm
Lead Out: Double Bending Pin
Operating Temperature: -20----+70 °c
Storage Temperature: -55----+80 °c
Item | Symbol | Min | Recommended | Max | Unit |
Filament Voltage | Ef | 5.2 | 5.5 | 5.7 | Vac |
Grid Voltage | ec | - | 30.0 | 35.0 | Vp-p |
Anode Voltage | eb | - | 30.0 | 35.0 | vp-p |
Duty Factor | Du | - | 1/16 | - | - |
Pulse Width | tp | - | 100 | - | |
Operating Temperature | Top | -20 | - | +70 | ℃ |
Storage Temperature | Tstg | -55 | - | +80 | ℃ |
