high purity synthetic extruded vibrated molded isostatic graphite round block
- Category: Other Graphite Products >>>
- Supplier: Zibo Yinxuan Carbon Technology Co. Ltd.
Share on (1152952697):
Product Overview
Description
high purity synthetic extruded vibrated molded isostatic graphite round block
Product Description
Advantages:
1,High quality,competitive price
2,Steady supply ability
3,Professional QC team, sales team service
4,precision machining
Type | Model | Bulk Density | Flexural Strength | Compressive Strength | Specific Resistivity | Ash Content |
Extruded | YX-ER | 1.55~1.60g/cc | 8.0Mpa min | 15.0Mpa min | 8.0µΩm max | 0.3% max |
YX-E1 | 1.63~1.70g/cc | 11.0Mpa min | 21.0Mpa min | 6.5µΩm max | 0.3% max | |
YX-E2 | 1.66~1.73g/cc | 13.0Mpa min | 25.0Mpa min | 6.0µΩm max | 0.3% max | |
Vibrated | YX-VP1 | 1.58g/cc min | 10.0Mpa min | 20.0Mpa min | 10µΩm max | 0.3% max |
YX-VP2 | 1.72g/cc min | 13.0Mpa min | 26.0Mpa min | 8.0µΩm max | 0.3% max | |
YX-VT1 | 1.68g/cc min | 11.0Mpa min | 23.0Mpa min | 9.0µΩm max | 0.3% max | |
YX-VT2 | 1.72g/cc min | 15.0Mpa min | 29.0Mpa min | 8.0µΩm max | 0.3% max | |
YX-GT1 | 1.69g/cc min | 14.0Mpa min | 30.0Mpa min | 10µΩm max | 0.3% max | |
YX-GT2 | 1.72g/cc min | 17.0Mpa min | 34.0Mpa min | 7.5µΩm max | 0.3% max | |
Molded | YX-M23 | 1.78g/cc min | 30.0Mpa min | 60.0Mpa min | 10µΩm max | 0.1% max |
YX-M34 | 1.83g/cc min | 35.0Mpa min | 70.0Mpa min | 10µΩm max | 0.1% max | |
Isostatic
| YX-D1 | 1.79g/cc min | 35.0Mpa min | 70.0Mpa min | 10µΩm max | 0.1% max |
YX-D2 | 1.85g/cc min | 42.0Mpa min | 85.0Mpa min | 10µΩm max | 0.1% max |
Our Services
1. Experienced engineers to offer solution for improving graphite cost efficiency.
2. Customize production
3. Close and attentive after-sales service
4. Technical support and services
5. Drawing CAD and solidworks Design
• yinxuan carbon is with high capability to machine one-body graphite with thin thickness, large sizes and splicing graphite plates.
• based on different technical requirement, in order to improve application effect and extand service life of graphite launder, we could be selective to do additional treatments to the products such as anti-oxidation, impermeability or strengthening treatments.
• extruded, vibrated. molded and isostatic graphite plate, bloack and round could be supplied according to customers' needs.
• when customers give specific technical requirements, our products are able to be or over customers' expectation.
Company Information
Zibo Yinxuan Carbon Technology Co.,Ltd. is engaged in researching, production and marketing various graphite machined parts for 10 years. Series of Yinxuan owned technologies of special treatment for graphite products can largely improve the performance of graphite prdoucts applied in non-ferrous metal casting, glass casting, precious metal industry, alloys smelting, various industrial furnaces etc. Yinxuan Carbon is equipped with advanced machining capability and responsible customer-oriented service principle. Yinxuan Carbon supplies not only graphite products, but also graphite solutions according to customers' different applicaitons, aiming at supplying best cost-efficiency graphite products and services.
Based on this, Yinxuan Carbon can be your reliable supplier.
Yinxuan Carbon offers not only graphite products, but also solutions aiming at best cost efficiency.
