HSS(High speed steel) Steel Mould Steel SKD11 H13 H11 D2 M2 M35
- Category: >>>
- Supplier: Huangshi Youli Special Steel Co. Ltd.
Share on (1166944252):
Product Overview
Description
Material: GB W6Mo5Cr4V2 ;ASTM M2;JIS SKH51;SKH9;DIN S6-5-2;DIN SC6-5-2;BS BM2;DIn 1.3343 High Speed Tool Steel
Standards:ASTM,JIS,GB,EN(DIN,BS,NF) Or Per as clients’ requires.
Product Basic Information:
1.Chemical Composition and Mechanical Properties(In Quenched & Tempered State):
Chemical Composition | Mechanical Properties(In Quenched & Tempered State) | ||
C | 0.80-0.90 | Tensile strength(MPA) | ----- |
W | 5.50-6.75 | Yield strength (MPA) | ----- |
Mo | 4.50-5.50 | Elongation(δ5/%) | ---- |
Cr | 3.80-4.40 | Reduction in Area (ψ/%) | ---- |
V | 1.75-2.20 | Impact (J) | ---- |
Mn | 0.15-0.40 |
Hardness |
≤255HB |
Si | 0.20-0.45 | ||
S | ≤0.030 | ||
P | ≤0.030 | ||
2.Product Application Areas:
Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,
nuclear energy,chemical industry,electronic information,achine manufacture, petrochemical,
automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.
3.Similar steel grade & equivalent steel materials:
USA | Japanese | Gemany | British | France | International | Chinese |
ASTM&AISI&SAE | JIS | EN DIN | EN BS | EN NF | ISO | GB |
M2 | SKH51 SKH9 | 1.3343 | 1.3343 | 1.3343 | HS6-5-2S4 | W6Mo5Cr4V2 |
Product Sales Information:
Size | Diameter:20mm-1000mm Length:500mm-6000mm |
Origin place | Made In China |
Delivery Condition | Hot rolled,cold drawn,forged |
Surface require | Black,grinding,bright,polish |
Heat treatment | Quenched,Tempered,annealed |
Packing | seaworthy packing ,wooden case ,carton,woven bag or at client's requires |
Delivery time | In 10-50 days |
Trade Term | EXW,FOB,CIF |
Payments | T/T or L/C at sight |
Port | China main Port,such as shanghai,Dalian,Shenzhen port. |
MOQ | 1 Ton |
Company Main Products:
Alloy Steel | 4140 ,4142,42CrMo4,1.7225,SCM440,4130,SCM430,25CrMo4,1.7218,34CrNiMo6 1.6582,4340,SNCM439,36CrNiMo4,1.6511,SACN645,1340,SMn438,SNC236, |
Tool Steel | H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419, SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2 |
Bearing Steel | GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50 |
Spring Steel | 9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150, SUP10,51CrV4,1.8159 |
Stainless Steel | 321,sus321,1.4541,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028, 434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057, |
