Paper card Spot UV Oven completely solution supplier
- Category: Other Printers >>>
- Supplier: Lc Printing Industries Company Limited
Share on (1177326301):
Product Overview
Description
Product Description
| Features and Application: | Used in the field of post-printing by UV ink. Exposure through UV light onto the film of UV ink to let it dry. Drying to UV ink printed onto paper, PVC etc soft and thin substrates. Connecting with offset printer to cure UV ink. This machine is suitable for Spot UV process with flat vacuum screen printer; Curing some soft materials after coating by roller ; Entering mouth adjustable make diffrent objects curing; Temperature controlled automatically ensure Objects drying on lower temperature. |
| Package size: | M-50200UVC 1. Dimension: 2170×850×1420mm; 2. Gross weight: 295KG |
| Technical parameters: | M-50200UVC UV curing Machine 1.Conveyer width:500mm 2.Total wattage:7KW 3.Wind fan wattage:200W/380V 4.Conveyer motor wattage:1000W/1P/380V 5.ConveyEr speed:0~10m/min 6.Speed adjustment:Stepless 7.Lamp wattage:3KW/380V×2pcs; 8.Max height of production: 75mm. M-75200UVC UV Curing Machine 1.Max curing Objects:750×60mm(W×H) 2.Total Wattage:7KW 3.Fan Motor Wattage:1000W/380V 4.Transport Motor wattage:1000W/1P/380V 5.Conveyer speed:0~10m/min 6.Speed adjustment mode:stepless 7.Lamp wattage:3KW/380V×2pcs. 8.Max objects height: 75mm. |
| Performance: | 1. Teflon conveyor belt, and high temperature. 2 Brand-name motor driver, the speed stepless adjustment, convenient to adjust the conveyor speed based on product characteristics. 3. UV lamp intensity focused, long service life. 4. Electronic components (transformers, starters), control, precision, long life. 5. Ventilation function can quickly rule out the heat of the curing chamber, and reduced product deformation, increase lamp utility. |
Packaging & Shipping
Machine is very heavy, It is recommended to use mechanical forklift move and handling, avoid i nversion, Impact, Shake.
Our Services
- Printing machinery industry Alibaba 13 years golden supplier .
- 15 years of sales experience. areal understanding of customer need.
- Clearly marked price, earn consciencemoney. Profits no more than 20%.
Company Information
The world is only one China, China only one LC, we are the production and sale of pad printing machines, silk screen machines, bronzing machines and automatic printing equipment and world famous!
Excellence in product quality depends on the high precision machining equipment;
The company has dozens of leading domestic CNC, printing machines, silk screen machines, bronzing machines and other special printing equipment, data and standardized management in the forefront of the domestic.Excellence in product quality depends on the high precision machining equipment.
All Machine has CE certification.
CE of pad printers
CE of screen printers
CE of hot foil stamping machine
CE of UV exposure machine and UV curing machine. Etc
Our clients
FAQ
1.Q:Are you a factory or a trading company?
A:Our factory has over 25years printing machine manufacture experience,so you can trust us absolutely!We have a number of qualified technicians in the field of design and production saler,with which we can provide overall service for you at any time!
2.Q:Can you send me the video to show how the machine works?
A:Of course,we have made video of every machine and uploaded them to Youtube!
3.Q:How can i know your machine works well?
A:We shall test the machine working condition for you before delivery!
4.Q:How can i know your machine is designed for my products?
A:You can send us samples of you product and we test it on machine!
