outdoor 500 people luxury transparent wedding tent,wedding tent hall,wedding glass tent

Product Overview

Description

outdoor 500 people luxury transparent wedding tent,wedding tent hall,wedding glass tent

(size customized)





Product Description



1)Application:

outdoor 500 people luxury transparent wedding tent,wedding tent hall,wedding glass tent (MS series, A frame) can be widely used as the wedding tent, party tent, exhibition tent, conference tent, different kinds of festivals tent, hajj tent, corporate events tent, sports tent, & temporary, semi-permanent or permanent building purpose etc.

2)Materials:
Fabric: Double PVC coated polyester fabric, 650-900g/sq. m, water proof, UV resistance, anti-mildew, self-cleaning, fire retardant according to standard NFPA701 & DIN4102 B1/M2



3)Frame:

Hard pressed extruded aluminum 6061/T6, anodized surface finishing.

Main frame profile size: 152*120*4mm ;



4)Connections:

Hot-dip galvanized steel;



5)Life span:

Life span of fabric(cover & sidewalls): 8-10years;

Life span of aluminum frame: 20-30years



6)Structure safety parameters:

Wind load: 100km/h (0.5kn/M2)

Snow load: 25kg/sq.m



7)Color available:

White, red, yellow, blue, green, black, grey, transparent etc



8)Optional Accessories:
Ground anchor, anchor puller, weight plate, glass door, fire door, glass wall, ABS hard wall, Sandwich walls, auto-rolling door, decoration lining, flooring system, clear PVC windows sidewalls, transport rack for the glass door & walls, ramp etc; chairs , tables, & other furniture for the parties are also provided for your option.





Specification for transparent wedding tent (MS series, A frame), pls refer to chart:





Type	Span (m)	Side height (m)	Ridge height (m)	Bay Distance (m)	Roof Pitch	Longest Component (m)	Wind Load (km/h)
MS8/3.3-5	8	3.3	4.5	5	18°	5.7	100
MS10/3.3-5	10	3.3	5	5	18°	5.7	100
MS12/3.3-5	12	3.3	5.3	5	18°	6.5	100
MS15/3.3-5	15	3.3	5.8	5	18°	5.7	100
MS16/3.3-5	16	3.3	5.7	5	18°	6.5	100
MS18/3.3-5	18	3.3	6.3	5	18°	6.5	100
Main frame Profile		152x120x4mm(4-channel)
Eave Connection		Hot-dip Galvanized Twin Steel Plate
Roof Fixing		Bar Tension
Frame Material		Hard Pressed Extruded Aluminum 6061/T6
Cover Material		Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m









  *Specialized in Producing different sizes of tents  base on unique requirements









                WHY CHÖOSE ÜS

• Guaranteeing quality but reducing cost by 16 years' experience

•Focusing on global PVC tents market and requirements.

• Innovating hardware design for more trendy and convenient

•  In order to improve efficiency,suppliers of ram material are neighbour.

• 100% inspection before exporting and 100% after sales service following.

•  Ongoing creation and innovation can go beyond.
