A grade 3k Carbon fiber fabric plain

Product Overview

Description

We are from Taiwan.

We can supply the TORAY T-300  carbon fiber fabrics price

for car parts and shoes parts

in weave pattern Twill 2x2

width(cm) 50~200

,if you need more information,please feel free to contact us.



JINSOR carbon fiber fabrics detail specifications
Carbon fiber fabrics application are as follows 1. carbon sporting goods: golf shaft,tennis racket,ski board,snow board,surfboard,fishing rod...
2. carbon car parts: hood,front fender,steering wheel,gear shift,mirror cover,trunk cover. 3. carbon shoes parts:shoes sole,shoes trim...
4. carbon boat parts:mast,kayak,loom,loom blade,boat shell.. 5. carbon electronic parts:speaker cone,mobile phone shell,carbon laptope shell.

Code No (pictures) weave pattern Thickness (mm) width(cm) weight(g/m2) counts/inch fiber photos warp weft warp weft JSC 0151P Plain 0.16 50~200 136 17 17 1.5K 1.5K JSC 0151T Twill 0.16 50~200 136 17 17 1.5K 1.5K JSC 0152P Plain 0.17 50~200 162 20 20 1.5K 1.5K JSC 0153P Plain 0.15 50~200 100 12.5 12.5 1.5K 1.5K JSC 0154P Plain 0.16 50~200 145 18 18 1.5K 1.5K JSC 0156P Plain 0.14 50~200 96 12 12 1.5K 1.5K JSC 0301P Plain 0.3 50~200 200 12.5 12.5 3K 3K JSC 0302P Plain 0.35 50~200 225 15 13 3K 3K JSC 0303P Plain 0.35 50~200 240 15 15 3K 3K JSC 0304P Plain 0.25 50~200 160 10 10 3K 3K JSC 0305P Plain 0.25 50~200 164 12.5 8 3K 3K JSC 0306P Plain 0.28 50~200 273 17 17 3K 3K JSC 0311T Twill 2x2 0.3 50~200 200 12.5 12.5 3K 3K JSC 0312T Twill 1x3 0.3 50~200 200 12.5 12.5 3K 3K JSC 0313T Twill 2x2 0.35 50~200 240 15 15 3K 3K JSC 0313T3 Twill 3x3 0.35 50~200 240 15 15 3K 3K JSC 0314T Twill 2x2 0.25 50~200 160 10 10 3K 3K JSC 0316T4 Twill 4x4 0.38 50~200 272 17 17 3K 3K JSC 0321S Satin 8H 0.42 50~200 368 23 23 3K 3K JSC 0322S Satin 5H 0.4 50~200 280 17.8 17.8 3K 3K JSC 0601P Plain 0.5 50~200 320 10 10 6K 6K JSC 0604P Plain 0.4 50~200 290 9 9 6K 6K JSC 0611T Twill 2x2 0.5 50~200 320 10 10 6K 6K JSC 0612T Twill 2x2 0.55 50~200 400 12.5 12.5 6K 6K JSC 0613T Twill 2x2 0.35 50~200 205 6 7 6K 6K JSC 0621S Satin 5H 0.55 50~200 380 12 12 6K 6K JSC 1201P Plain 0.65 50~200 510 8 8 12K 12K JSC 1202P Plain 0.65 50~200 576 8 10 12K 12K JSC 1204P Plain 0.6 50~200 378 6 6 12K 12K JSC 1211T Twill 2x2 0.65 50~200 510 8 8 12K 12K JSC 1212T Twill 2x2 0.65 50~200 576 8 10 12K 12K JSC 1213T Twill 2x2 0.7 50~200 650 10.5 10.5 12K 12K JSC 1214T Twill 2x2 0.6 50~200 378 6 6 12K 12K JSC 1215T Twill 2x2 0.6 50~200 630 10 10 12K 12K JSC 2401P Plain 0.85 50~200 770 5 7 24K 24K SCP100 Plain 0.13 100 100 1.6 1.6 16mm spread 12K 16mm spread 12K
