675/750/825/1600cfm Ingersoll Rand / Doosan Portable Air Compressors

Product Overview

Description





675 – 825 cfm
Performance features
• 3/8" safety chains with grade 43 hooks
• 1-year/2,000-hour package warranty
• 2-year/4,000-hour warranty airend standard, extended to 5-year/10,000-hour warranty when genuine fi lters, fl uids and parts from an authorized Doosan Infracore Portable Power dealer are used at the prescribed maintenance intervals
• 500-hour engine oil service/1,000-hour airend oil service
• Automatic safety shutdowns for high discharge air temperature, low engine oil pressure, high engine coolant temperature and low
fuel level
• Backlit gauges
• Easy maintenance of coolers, fi lters and fl uids
• Fuel/water separator as primary fi ltration
• Heavy-duty 14-gauge fenders
• Heavy-duty A-frame detachable drawbar with adjustable-height pintle eye
• Large, powerful 1,150 CCA batteries
• Microprocessor-controlled engine with optimal compressor performance
• Secured lifting eye with interior release pin
• Slam latch handles with padlock provisions
• Standard engine auxiliary drive provision Available options (factory installed)
• Aftercooler plus water separator with 20 degree F approach temperature
• Central drains for single-point fl uid maintenance
• Cold start kit includes engine block heaters, engine oil pan, batteries
• Dual pressure regulation: HP units available with 100/150 psi; XP units available with 100/125 psi
• Full galvanneal sheet metal
• Hydraulic surge brakes with three-position hitch (subject to local DOT regulations)
• IQ System® aftercooler plus particulate and coalescing fi lters with patented condensate disposal system for cleaner, drier air
• Less running gear includes isolation mounts for truck, trailer or permanent pad installation
• Multiple air outlets: (1) 2" and (3) 1-1/4" valves 750 – 1000 cfm Performance features
• Compact size for superior maneuverability
• Galvanneal sheet metal enclosure for ultimate corrosion protection
• High-speed running gear is standard
• Large fuel tank lasts more than nine hours at 100% load
• Microprocessor-controlled engine panel increases effi ciency; backlit gauges include engine temperature, hour meter, volt meter, discharge air temperature, engine oil pressure, tachometer and fuel level
• Rear steps allow easier access to radiator for refi lling engine coolant Available options (factory installed)
• Aftercooler with water separator with 20 degree F approach temperature
• Central drains for single-point fl uid maintenance
• Cold-start kit includes engine block heaters, engine oil pan, batteries
• Dual pressure regulation
• Hydraulic surge breaks
• IQ System® aftercooler plus particulate and coalescing fi lters with patented disposal system for cleaner, drier air
• Wagon or less running gear options
1300 – 1600 cfm
Performance features
• 110% fl uid containment frame
• Microprocessor-controlled engine with optimal compressor performance and diagnostics
• 12-step sheet metal pre-treatment process plus epoxy powder topcoat
• Easy maintenance of coolers, fi lters and fl uids
• Backlit gauges
• 500-hour engine oil/1,000-hour airend oil service
• Heavy-duty A-frame detachable drawbar with adjustable pintle eye
• Construction-grade pedestal jack stand
• 1/2" safety chains with grade 70 hooks
• Fuel/water separator as primary fi ltration
• Large, powerful 1,400 CCA batteries
• Slam latch handles with padlock provisions
• Secured lifting eye with interior release pin
• Automatic safety shutdowns for high discharge air temperature, low engine oil pressure, high engine coolant temperature and low fuel level
• 1-year/2,000-hour package warranty
• 2-year/4,000-hour warranty airend standard, extended to 5-year/10,000-hour warranty when genuine fi lters, fl uids and parts from an authorized Doosan Infracore Portable Power dealer are used at the prescribed maintenance intervals Available options (factory installed)
• Aftercooler plus water separator with 20 degree F approach temperature
• Automatic engine/oil replenishment system
• Automatic start/stop controller with remote start
• Central drains for single-point fl uid maintenance
• Cold start kit includes engine block, engine oil pan and battery heaters
• Emergency stop
• Galvanneal sheet metal (air intake panels are standard)
• IQ System® aftercooler plus particulate and coalescing fi lters with a patented condensate disposal system for cleaner, drier air
• Less running gear includes isolation mounts for truck, trailer or permanent pad installation
• Low ambient system included with aftercooler blowdown, airfl ow control and orifi ce heaters for any temperature operation
