14 500Hp Diesel Water Pumps For Sale Agricultural Irrigation

Product Overview

Description

14-500Hp Diesel Water Pumps For Sale Agricultural Irrigation



Diesel Water Pump Specifications

Model of Diesel pump set	VKL400-20P (Q=400m³/h H=20m)
Usage	farm irrigation/ water supply
Outflow	400m³/h
Head lift	20m
Treated Water	fresh water/ river water
Diesel Engine
Model	K4102D (OEM Ricardo Diesel Engine)
Rated Output/Max output(KW)	33/39.6
Rated Speed (r/min)	1500
Starting Method	12V DC Electric motor
Cooling Method	closed water cooling
Governing Method	Mechanic governing
Intake Method	natural aspiration
Cylinders	4
Bore/Stroke	100/115mm
Type	closed water cooling,in-line,4 stroke,humid liner,direct injection
Water Pump
Model	IS200-150-250
Type	single grade,single suction,centrifugal pump
Outflow/head lift	400m³/h,head lift:20m
Suction lift	6m
Shaft Power	26.2KW
Inlet diameter	200mm(8inch)
Outlet diameter	150mm(6inch)
Casing material	cast iron
Shaft material	cast iron
Impeller material	cast iron
Sealing method	stuffing sealing
Control System
Display/Control System	Display oil pressure,charging current,water temperature,oil temperature.
