cooling and heating tank mixing vessel

Product Overview

Description

cooling and heating tank mixing vessel

three-layer mixing vessel mixing tank

Stainless steel tank can be stainless steel mixing tanks, stainless steel mixing vessels, made of stainless steel and used to liquid chemical mixing and reaction

  cooling and heating tank mixing vessel

 three-layer mixing vessel tank

 three-layer mixing vessel tank Application Field:

Can be used as raw water, milk, juice or liquid storage tank, mixing tank, reactor, fermenter or mixing kettles.

Mixing vessel Structure:



Mixing tank can be

1. Single layer mixing tank vessel

2. Double layer mixing vessel tank with insulation material

3. Three layer mixing tank with heating jacket

Material of tank is stainless steel

mixing vessel Standard Features:

Quick-open manhole

Digital thermometer

T type cleaning head

Adjustable triangular bracket

Optional Feature: Climbing ladder

cooling and heating tank mixing vessel

three-layer Mixing Tank vessel:

It can be used as dosage tank, material mixing tank in dairy, beverage and juice industry.

Specifications:

Capacity (L)	Tank Diameter (mm)	Height (mm)	Inlet & Outlet Pipe Diameter (mm)	Agitator Motor Power (kW)	Agitator Speed  (rpm)
600	1000	2300	38	0.75	14/18/24/28/35/47/56/70/94
1000	1150	2530	38	1.1
1500	1280	2700	38	1.1
2000	1440	2910	51	1.1
2500	1520	3100	51	1.5
3000	1640	3200	51	1.5
3500	1700	3300	51	1.5
4000	1750	3500	51	1.5
5000	1880	3400	51	1.5
8000	220	4050	51	2.2
10000	2400	4200	65	2.2
15000	2750	4600	65	2.2
