This version have three size for options: 15.6",18.5",21.5",10",15",17",18",25",30"
Screen Size
15.6 Inch
18.5 Inch
21.5 inch
LCD Screen
TFT LCD Screen
TFT LCD Screen
TFT LCD Screen
Aspect Ratio
16:9
16:9
16:9
Resolution
1366(H)×3(RGB)×768(V)
1366(H)×3(RGB)×768(V)
1920(H)×3(RGB)×1080(V)
Contrast Ratio
600:1
1000:1
1000:1
Brightness
220cd/m2
250cd/m2
250cd/m2
Response Period
8ms
5ms
5ms
View Angle
U:35/D:45 L/R: 45
U:85/D:80 L/R: 85
U:85/D:80 L/R: 85
Light Source
LED
LED
LED
OSD Language
OSD Multilingual optional
OSD Multilingual optional
OSD Multilingual optional
Analog Adjustments
Brightness, Contrast, Chroma(0~100)
Brightness, Contrast, Chroma(0~100)
Brightness, Contrast, Chroma(0~100)
Color System
PAL/NTSC optional
PAL/NTSC optional
PAL/NTSC optional
Video Input
1VP-P 75Ω VGA signal input (optional)
1VP-P 75Ω VGA signal input (optional)
1VP-P 75Ω VGA signal input (optional)
Image Display(two)
16:9
16:9
16:9
Interface
RCA input or VGA input (optional)
RCA input or VGA input (optional)
RCA input or VGA input (optional)
Power Supply
DC+10.5—32VDC
DC+10.5—32VDC
DC+10.5—32VDC
Product Dimension
L:389mm×W:236.5mm×H:41mm
L:463mm×W:283mm×H:46mm
L:530mm×W:321mm×H:47mm
Operating Temperature
-20~60°C
-20~60°C
-20~60°C
Storage Temperature
-20~75°C
-20~75°C
-20~75°C
Power Consumption
18W
25W
30W
Company Information
Founded in 2007,Xiamen Harine Electronics Co., Ltd. has become a professional designer and manufacturer of vehicular electronics products in Xiamen, Fujian Province, China. Harine has passed the ISO/TS16949:2009 Quality System Certification. We have been assessed as a National Hi-tech enterprise specialized in the design, production and sales of Vehicular LCD&LED monitor, Vehicular audio & video system, rear view system and so on.
With the advantage of long-period experience in vehicular products, powerful R&D team, good team sense and efficient and effective production, Harine sells the products to all over the world and has been approved to be the first choice in the field.
Presently, our factory covers an area of 3,000 square meters, has about 200 employees and 60 million RMB turnovers in 2014.
We firmly believe that quality is the most important. Most of our products have been CE Certificated, FCC Certificated or E-mark approved.
