Phenolic foam insulation boards pre insulated air duct panel

Product Overview

Description

Phenolic foam insulation boards pre insulated air duct panel



Phenolic Foam Pre-Insulated Air Duct Panel



Similar to PUR / PIR pre-insulated duct panel,  we offer a new option that is phenolic foam pre insulated air duct.    It is better than PUR / PIR because it has the same thermal insulation performance but better fire resistance performance.



Unlike PUR / PIR,  the phenolic foam pre insulated air ducts can reach Class A fire safety.  In fire, its smoke density is only 2% and the smoke is not toxic.  There will be no drips in fire.



Compared with PUR / PIR, the phenolic foam pre insulated air ducts are not more expensive but safer when bring fire into consideration.  Phenolic foam is very good at dimension / shape stability.  As time passed, there is nothing change but color.  PUR / PIR has aging / shrinking / fragile problem as time passes.









Technical Properties of Phenolic Foam Boards



Properties	Phenolic Foam (PF)
Density (kg/m3)	40~60
Thermal Conductivity W/(m.K)	0.02~0.03
Heat Insulation	As good as Polyurethane Foam (PUR) or Polyisocyanurate foam (PIR)
Fire Resistance (ASTM E84)	A
Drips in Fire	No
Oxygen Index	>36
Max. Smoke Density	2%
Smoke Toxicity	Non-toxic
High Temperature Resistance (°C)	150
Low Temperature Resistance (°C)	-250
Dimension Stability	Only color change
Water Absorption	Low (<1.9%)
Environmental friendliness	CFC free HCFC free Fiber Free
Resistance to Bacteria / Virus	Yes
Sound Insulation	Good
Rigidness / Compressing Strength	Much better than Rock wool / Glass wool
Construction Difficulty	Light weight - Easy to process and install
